Single-side Hot and Cold Laminator
HZSC-1700F2(Pneumatic)
Optimum performance
1.Large-diameter high quality Top-heated
2.Adjustable settings for increased capacity and versatility
3.Double sided Hot&Cold lamination
4.Unique anti-tilt and anti-fold system ensures clear output
Easy to use
1.Automatic pressure and nip gap adjustment
2.Simple film tension adjustment
3.Light weight drop-in supply shafts with auto-grip for easy loading
4.Roll-to-roll operation capacity
5.Foot pedal switch for pieces accurate application
Safety
1.Foot switch for hands free operation
2.Laser safety eyes and 2 emergency stops
3.CE
| Parameter | HZSC-1700F2 |
| Max lamination width | 1620mm/64" |
| Max lamination thickness | 30mm/1.2'' |
| Max Speed | 8m/min |
| Max temp | 150°C/302 °F |
| Up and Down | Air cylinder |
| Heating | Infrared |
| Warm up time | 15-20min |
| Power consumption | 0.9-1.8kw/h |
| Power input | 4300w |
| Volt | 110v/220v |
| N.W | 260kg |
Guarantee term
1. One year free warranty, main parts are free of charge when problem happens during the guarantee period, 6 months for the rollers.
2. Lifetime free maintenance service.
3. Free training course at our factory with professional engineer.
4. We provide consumable part at agent price when you need replacement.
5. We can provide door to door technical support to agents, if necessary.
| Configuration |
| 1.180w speed-adjustable torque motor |
| 2.Imported silicon roller with the diameter of 1300 prevents conglutination |
| 3.Pressure adjustable pneumatic lift device |
| 4.Reversible aluminum work table |
| 5.Deigned device automatically take up material and remove backing paper |
| 6.Non-contact infrared temperature control system |
| 7.Anti-tilt and anti-fold device |
| 8.Professional anti-static device |
| 9.Jog foot pedal |
