Product name: ASCO Low price pulse valve
SGC Series pulse valves are designed specifically for dust applications with high flow, long life and fast on / off switching characteristics, to ensure economic and reliable work.
Angle valve body. Special stainless steel piston / diaphragm, and new flow theory supply unique characteristics for operation
High-quality TPE piston / diaphragm, long service life, wide working temperature range
Stainless steel clamps, bolts rust and jamming will not happen, maintenance quickly and easily.
Low price SCG353A044 pulse valve - Ecnomic one
SCG353A044 pulse valve - normal one
1. Feature: ASCO series, copy, same size with ASCO valve.
2. Material: Aluminum alloy
3. Use: For dust collector
4. Capability: Top Quality, Large Stock, Quick Shipping
5. MOQ: USD3000, small order is available for trial order
7. Welcome OEM designs and manufacture
8. Packing: Carton normally
9. Port size: 1"
Pulse valve specification
| Type | Port Size | Orifice | Kv/Cv | Pressure | ||
| M3/h | I/min | Mix | Max | |||
| SCG353A043 | 3/4" | 25 | 14 | 233 | 0.3 | 8.5 |
| SCG353A044 | 1" | 25 | 23 | 283 | 0.3 | 8.5 |
| SCG353A047 | 1 1/2" | 52 | 46 | 768 | 0.35 | 8.5 |
| SCG353A050 | 2" | 66 | 77 | 1290 | 0.35 | 8.5 |
| SCG353A051 | 2 1/2" | 66 | 92 | 1540 | 0.35 | 8.5 |
| SCG353B060 | 3" | 75 | 170 | 2833 | 1 | 6 |
