Hot selling 720P AHD CCTV DVR with 2 sata interface and HDMI output
Feature:
1. Preview resolution: 720P/960H, with HDMI output.
2. 2 SATA Hard Disk Interface (2.5"/3.5" SATA, Up to 8TB)
SPECIFICATION
| Model | AS-AHDVR0450 |
| System | |
| Main Processor | ARM Cortex A9 Processor |
| Operating System | Embedded LINUX |
| Video | |
| Input | 4 Channel, AHD |
| Output | 1 VGA, 1 TV, 1 HDMI |
| Audio | |
| Input | 4Channel, RCA |
| Two-way Audio | NO |
| Output | 1 Channel, RCA |
| Alarm | |
| Sensor Input | NO |
| Output | NO |
| Motion Detection | 4 Channel |
| Trigger Events | Recording, PTZ, Tour, Email |
| Email Alarm | Send Strings to The Designated E-mail |
| PTZ | |
| Interface | RS485 |
| Protocol | Pelco-D, Pelco-P |
| Baud Rate | 1200~115200 |
| Address | 0~255 |
| Display | |
| VGA | Resolution: 800×600, 1024×768, 1280x720, 1280×1024, 1920x1080 |
| HDMI | Resolution: 720P(1280×720), 1080P(1920×1080) |
| Display Split | 4 Channel / 1Channel |
| Privacy Masking | 4 Rectangular Zones (Each camera) |
| OSD | Camera Title, Time, Video Loss, Motion Detection, Recording |
| Recording | |
| Video Compression | H.264 |
| Audio Compression | ADPCM |
| Resolution | 720P(1280×720), 960H(P:960×576/N:960×480) |
| Video Quality | Best/Fine/Normal |
| Record Rate | 720P(1280×720 100fps/120fps), 960H(P:960×576 100fps/N:960×480 120fps) |
| Record Mode | ManualTimerMotion Detection |
| Playback & Backup | |
| Sync Playback | 4 Channel / 1Channel |
| Remote Playback | 4 Channel/ 1Channel |
| Search Mode | ALL, Channel, Manual, Time, Date, Motion Detection |
| Playback Functions | Play, Pause, Stop, Rewind, Fast Play, Slow Play, Digital zoom |
| Backup Mode | USB Device/Network |
| Network | |
| Interface | 1 RJ45 10M/100M Adaptive Ethernet Interface |
| Network Functions | HTTP, IPv4,IPv6, TCP/IP, DHCP, DNS, DDNS, NTP |
| DDNS | 3322, Dyndns, changeip, no-ip |
| Web Browser | IE6-11, Firefox, Chrome (Under Windows System) |
| CMS Software | Support Windows XP /Windows Vista/Windows 7/Windows 8 |
| Extra Stream | D1/CIF/QCIF(1~25fps) |
| Smart Phone | iPhone, iPad, Android, Android Pad |
| Hard Disk Driver | |
| Interface Type | 2 SATA Interface |
| Capacity | Up to 8TB Capacity |
| General | |
| Language | Support 19 languages (Chinese, English, polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, Persian, Germany, France, Portugal, Turkey, Spain, Italy, Hungary, Romania, Korean) |
| USB Interface | 2 USB 2.0 Interfaces |
| Power Supply | DC12V/3A |
| Working Environment | -10~55℃/10~90% |
| Dimension (W×D×H) | 354mm×245mm×45mm |
| Weight | 4kg (Without HDD) |
You could check the image on PC by our free software CMS
Or on your Phone App : FREEIP
Strictly Quality control
Shipping:
By Express: FedEx, DHL, UPS, TNT..., we have cooperate with these Express company, and once we get your order, we can find the lowest shipping cost for youa
By Air: Can be shipped by our company forwarder or your own forwarder
By sea: Can be shipped by our company forwarder or your own forwarder
*We afford the 50% freight when the product return to repair in warranty period.
1.WIFI IPC&NVS
enya(at) Skype: enya.acesee TM: cn1513744887
ACESEE Sub-Brand of Longse Electronics Limited
With 15,000 square meters factory, 80 engineers for R&D depart, over 1,000 employees engaged in market, 28 full new moving assemble lines and 7 SMT lines...
Welcome you come to visit our factory and office!
Our products are certified by ISO9001:2008, CE, RoHS, FCC and other international certificate, also with good reputation of Grade A and top 100 Chinese security companies in domestict market.
We have participated various of international fair, such as in Poland, Russia, Brazil, and Las Vegas, HK etc, also domestic exibition, eg, Canton Fair, or CPSE and so on.
You could pay for the order via: T/T, L/C, Paypal
own shipping forwarder.
Q: How long is the delivery time?
A: Sample order is around 7 working days after payment balanced, bulk order is 12 working days .
Q: How long is the warranty?
A: All of product is two years warraty after shipment.
Q: What's the MOQ?
A: No MOQ for your first order, at least 10pcs at next order.
Q: Why do you choose us ACESEE?
A1. All of our product is 48 hours aging test
A2. Provided free CMS software
A3. Updated software version promptly
A4. Provided free technical support
A5. Updated full price list per month as per the feedback of security market
A6. Excellent pre-sale and after-sale service from ACESEE
Got more question? Welcome to contact us in any way now!
Pricelist will send to you right according your requirement!
