ACESEE 4CH HD CVR CVI DVR Kit With HD CVI Camera

ACESEE 4CH HD CVR CVI DVR Kit With HD CVI Camera thumbnail-1
ACESEE 4CH HD CVR CVI DVR Kit With HD CVI Camera photo-1
US$ 10 - 80 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ACESEE
Model Number:
CVR-04HNC
Contact Supplier Request Quote Chat Now
Longse Electronics Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou & Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ACESEE
Model Number CVR-04HNC

ACESEE 4CH HD CVR CVI DVR Kit With HD CVI Camera

ACESEE 4CH HD CVR CVI DVR Kit With HD CVI Camera



cvi dvr kit

Product Description

cvi dvr kit



ACESEE 4CH HD CVR CVI DVR Kit With HD CVI Camera



Model NO. CVR-04HNC10 CVR-04HNC30
Package
CVR 1x4CH 720P/960P AS-CVR5104D
Camera 4xAVHN20C100 4xAVHN20C130
BNC Cable 4x20M BNC Cable ACB-20DB
Mouse 1xUSB 2.0 Mouse
Controller 1xIR Remote Controller
Power Cable 1x5CH Power Splitter Cable
Adaptor 1x3A Power Adaptor+1xPower Cable (US, EU, UK, AU Plug is Optional)
Weight 7.5KGS/SET
Camera Model AVHN20C100 AVHN20C130
Image Sensor PO3100K AR0130
DSP DH9801 DH9801
Image Resolution PAL: 25fps@720P(1280×720); NTSC: 30fps@720P(1280×720)
Effective Pixels 1280(H)×720(V) , 1MP
TV System PAL/NTSC
Electronic Shutter 1/25s~1/50,000s , 1/30s~1/60,000s
Sync System Internal
Usable Illumination 0.01Lux/F2.0 0.01Lux/F2.0
S/N Ratio ≥50dB
Scanning System Progressive Scan
Video Output Mode CVI(BNC)
Lens
Focus Length Board Lens 3.6mm/F2.0
Focus Control Fixed
Lens Type Fixed
Pixels 2M Pixels
Night Vision
Infrared LED 5X24PCS
Infrared Distance 20M
IR Status Under 10 Lux By CDS
IR Power On CDS Auto Control
Camera Features
Day/Night Auto (ICR) / Color / B&W
OSD Menu Language No
White Balance Auto
Gain Control Auto
Noise Reduction 3D NR
Picture Adjustment No
OSD Support No
General
Weatherproof Housing YES, IP66
Anti-cut Bracket YES
Dual Voltage NO
IR Cut Filter YES
Heater NO
Operation Temperature -10℃ ~ +50℃ RH95% Max
Storage Temperature -20℃ ~ +60℃ RH95% Max
Power Source DC12V±10%, 500mA
Dimension 142(W)x65(H)x63(D)mm
Weight 500g
Model AS-CVR5104D
System
Main Processor ARM® CPU Core (GM8287)
Operating System Embedded LINUX
Video
Input 4 Channel, CVI
Output 1 VGA, 1 HDMI
Audio
Input 1 Channel, RCA
Two-way Audio YES
Output 1 Channel, RCA
Alarm
Sensor Input NO
Output NO
Motion Detection 4 Channel
Trigger Events Recording, PTZ, Tour, Alarm, Video Push, Email, Screen tips
Email Alarm Send Pieces to The Designated E-mail
PTZ
Interface RS485
Protocol Pelco-D, Pelco-P,  Sony, Sharp, Panasonic, Samsung and Other Protocols
Baud Rate 1200~115200
Address 0~255
Display
VGA Resolution:  1024×768, 1280×720, 1280×1024, 1920×1080
HDMI Resolution: 1080P(1920×1080), 720P( 1280×720)
Display Split 4 Channel / 1Channel
Privacy Masking 4 Rectangular Zones (Each camera)
OSD Camera title, Time, Video loss, Alarm, Motion detection, Recording
Recording
Video Compression H.264
Audio Compression G711A,G711U,PCM
Resolution 1080P(1920*1080), 960P(1280*960), 720P(1280×720), D1(P:704×576/N:704×480),
HD1(P:352×576/N:352×480), CIF(352×288/ 352×240), QCIF(P:176×144/N:176×120)
Video Quality Best/Fine/Normal
Record Rate PAL: 1080P@48fps, 960P@100fps, 720P@100fps, D1@100fps, HD1@100fps, CIF@100fps, QCIF@100fps
NTSC: 1080P@60fps, 960P@120fps, 720P@120fps, D1@120fps, HD1@120fps, CIF@120fps, QCIF@120fps
Record Mode ManualTimerMotion Detectionalarm
Playback & Backup
Local Sync Playback 4 Channel / 1Channel
Remote Sync Playback 4 Channel / 1Channel
Search Mode ALL, Channel, Manual, Time, Date, Motion Detection
Playback Functions Play, Pause, Stop, Rewind, Fast play, Slow play
Smart Phone Playback Support
Backup Mode USB Device/Network
Network
Interface 1 RJ45 10M/100M Adaptive Ethernet Interface
Network Functions HTTP, IPv4,IPv6, TCP/IP, SMTP, DHCP, DNS, PPPOE, DDNS,NTP,DST
DDNS Quick DDNS(free of charge), 3322, Dyndns
Web Browser IE8-11, Google Chrom , Firefox
CMS Software Support Windows XP /Windows Vista/Windows 7/Windows 8
Extra Stream D1/CIF/QCIF(1~25fps)
Smart Phone iPhone, ipad,  Android
Hard Disk Driver
Interface Type 1 SATA Interface
Capacity Up to 8TB Capacity
General
Language Simplified Chinese, Traditional Chinese, English, Italian, Spanish, Japanese, Russian, French, German, Portuguese,
Turkey, Poland, Romania, Hungary, Finnish, Hebrew, Brazil, Persian, Arabian, Czech,Bulgaria, Slovak, Dutch,
Greece, Indonesia, Switzerland, Vietnamese, Thai
USB Interface 2 USB 2.0 Interfaces
Power Supply DC12V/3A
Working Environment -10~55℃/10~90%
Dimension (W×D×H) 335mm×270mm×55mm
Weight 2.5kg (Without HDD)









ACESEE 4CH HD CVR CVI DVR Kit With HD CVI Camera

Packaging & Shipping

 ACESEE 4CH HD CVR CVI DVR Kit With HD CVI Camera

Shipping:

By Express: FedEx, DHL, UPS, TNT..., we have cooperate with these Express company, and once we get your order, we can find the lowest shipping cost for youa

By Air: Can be shipped by our company forwarder or your own forwarder

By sea: Can be shipped by our company forwarder or your own forwarder



*We afford the 50% freight when the product return to repair in warranty period.



Company Information

ACESEE Security Limited is a professional manufacturer and solutions provider in the security and surveillance field. Since its foundation in 2007, ACESEE has aimed to be a top international security company, and provide high quality and prominent marketing service. We catch up with international market trend timely. We develop IP Cameras in an early time, and now we own various of IP products list, like 1MP to 2.4MP high resolution cameras with chip from HISILICON, TEXAS INSTRUMENTS and AMBARELLA. And investment on IP solutions is expanded, more and more will be brought to you in the near future. We do believe our abundant products could meet your requirements. However, IP solutions will not be the end, instead it is just the beginning, because we ACESEE never stop moving on.

 ACESEE 4CH HD CVR CVI DVR Kit With HD CVI Camera

ACESEE 4CH HD CVR CVI DVR Kit With HD CVI Camera

Welcome to visit ACESEE! ^_^

If you have any questions or request, pls contact Rita.

Skype ID: rita.acesee

Whatsapp: 86 13808860995

TM ID: cn1512088157



Pls add my telephone number 86 13808860995 to your contact.



I am online in skype, TM, whatsapp, wechat, Line...





Our Services


*OEM and ODM service is acceptable

1.Logo Printing

2.DIY Sticker/Label

3.Branding Your Boxes

4.Boot Logo





FAQ



Q: How long is the delivery time?

A: Sample order is around 7 working days, bulk order is 12 working days.

Q: How long is the warranty

A: All of product is two years after shipment

Q: What's the MOQ?

A: No MOQ for your first order, at least 10pcs at next order

Q: Why do you choose us ACESEE?

A1. All of our product is 48 hours aging test

A2. Provided free CMS software

A3. Updated software version promptly

A4. Provided free technical support

A5. Updated full price list per month as per the feedback of security market

A6. Good pre-sale and after-sale service from ACESEE
