Pneumatical Transpoter

Name: Pneumatical Transpoter
Brand: Mingfeng Machine
SKU: 126309187
Availability: InStock

US$ 2,330 - 3,620 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Mingfeng Machine

Model Number:

MFSR-100H

Zhangqiu Mingfeng Machinery Manufacture Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Mingfeng Machine

Model Number MFSR-100H

Application Industrial Blower

Type Roots Blower

Pressure Other, High Pressure, 63.7kpa-98.0kpa

Power Source Pneumatic

Rated Power 11kw -- 22kw

Rated Voltage 220V--525V

Specifications

1.German imports OPTI belt.
2.Sweden SKF bearing.
3.Higher than 5 standard gear
4.Passed the ISO9001-2000 certification.

Brand	Mingfeng Machine	Model	MFSR-100H
Item	Roots blower	Type	MFSR series three lobes
Flow rate	4.10m3/min -- 8.62m3/min	Pressure	63.7kpa -- 98kpa
Motor power	11kw -- 22kw
Frequency	50HZ, 60HZ	Voltage	220V—525V
Bore	100mm	Dimension
Drive type	Direct coupling or belt transmission	Cooling type	Air cooling
Weight	510kg	Package dimension
Features: 1 positive displacement blower, no compression, air conveying is smooth, there is small flow rate changes along with pressure changes. 2 tri-lobe linear-shaped impeller making inlet and outlet pulsation quiet with low noise and vibration. 3 special impeller of mesh curve and small enclosure making roots blower high efficiency, low energy consumption. 4 small size, light weight and elegant appearance. 5 with high-precision synchronous hard-toothed surface gears ensure long life. 6 much cleaner with no oil 7 with nitrile rubber seal rings 8 Swedn SKF brearings 9 Germany OPTI belts
Usage:sewage treatment,biogas firing system,printing pool stir, flour, aquaculture, pneumatic conveying, electric power and cement industries etc.
Accessory: suction silence (with air filter). Discharge silence, pressure relief valve, pressure gauge, cock, vibration-isolating base, rubber vibration isolator, expansion joint, check valve, commong basement,first fill of lubricantion oil,
Payment terms: 40% T/T in advance, 60% T/T against copy of B/L; L/C at sight
Delivery time: within two weeks
