Dimensions | |
| Overall Length | 1030mm |
| Overall Height | 900mm |
| Overall Width | 570mm |
| Weights | |
| Total weight including batteries | 36.5kg |
| Total weight excluding batteries | 33kg |
| Maximum Loads | |
| Max.user's weight | 120kg |
| Max.load in the front basket | 10kg |
| Max.loading persons | 1 |
| Driving Features | |
| Max.speed forward | 8Km/h |
| Min.speed forward | 2Km/h |
| Reverse speed | 4Km/h |
| Turning radius | 140cm |
| Ground clearance | 4cm |
| Max.cross obstacle height | 5cm |
| Max.driving slope | 10 degree |
| Max.driving range | 15km |
| (Range depends on the circumstances during use,it can be less when hills,wind or loose surface such as gravel or sand.Range can also be vary under theuser's weight) | |
| Driving System and Tires | |
| Drive system | rear wheel with gear box |
| Motor | 24V/270W |
| Controller | 24V/50A |
| Brake system | eletro-magnetic parking brade Tires |
| PU tire size | 8x2.5 |
| Tire size(inflatable) | 8x2.5 |
| Batteries and Charger | |
| Batteries | li-ion 24V/14Ah |
| Battery charger | 120-230V/24V/2A |
| Max.charger current | 2A |
| Charging time to 80% charge | 6H |
| Charging time to full charge | 7H |
| Additional Datas | |
| Seat width | 380mm |
| Backrest height | 340mm |
| Seat depth | 360mm |
| Armrest height from seat | 210mm |
| Seat height from scooter platform | 400mm |
| Optional Accessories | |
| Seat belt for additional stability | |
| External charger adapter for charging batteries not mounted to the scooter | |
Standard packing:one unit one carton
Size:1030x900x570mm
Loading Capacity: 59units / 20 FT , 140units / 40 HQ
After-sales Service:
1 year warranty for scooter &wheelchair&battery;1 year for Electronic control
3 years for frame &other metal parts;
Within warranty free accessories & video provided,free training service.life-time technical support service
Suzhou Sweetrich Vehicle Industry Technology Co., Ltd established in Suzhou Industry Park located in Jiangsu Province, China in 2007 is a hi-tech based company that has its own brand lines for R&D and production of electric vehicles, for example, electric scooters and power wheelchairs. It has been funded with 50 million investment and covered an area of 60 acres including 30,000 square meters of factory plants.
"Prosperity (Xin) comes from joy & care(Xin)" – This is the reason our company named as “ Xin Xin”. We hope to bring all our clients the joy & care with our excellent products and sincere service. We hope to establish the long-term and friendly relationship of cooperation to join hands in creating a wonderful future!
