1. Various kinds of models, brands for your optional;
2. Large volume, small dimension, high efficient;
3. Air cooled;
4. Compressor brand: Copeland, Bitzer, Sanyo, etc for your optional;
5. Safe and reliable system.
6. Applications: for cold room, supermarket refrigeration equipment, hotel refrigeration equipment, restaurant refrigeration equipment, etc.
| Model | HS261CH2 | HS263CH3 | HS303CH3 | HS373CH3 | HS453CH3 | HS235CH3 | HS603DH3 | HS753DH3 | HS903DH3 | |
| Refrigerant | R22 | |||||||||
|
Applicable temperature ( °C) |
0-15 | |||||||||
| Power supply | 220V/50HZ | 380V/50HZ | ||||||||
| Scroll compressor model | C-SB261H5A | C-SB263H8A | C-SB303H8A | C-SB373H8A | C-SB453H8A | C-SBR235H38A | C-SC603H8H | C-SC753H8H | C-SC903H8H | |
| 3.5hp (side air outlet) | 3.5hp (side air outlet) | 4hp (side air outlet) | 5hp (side air outlet) | 6hp (side air outlet) | 7hp (side air outlet) | 8hp (top air outlet) | 10hp (top air outlet) | 12hp (top air outlet) | ||
| Max. running current (A) | 12.9 | 4.9 | 5.5 | 6.6 | 7.7 | 8.8 | 10.6 | 12.8 | 15.1 | |
| Condenser | fan quantity | 1 | 1 | 1 | 2 | 2 | 2 | 1 | 1 | 1 |
| blowing rate (m3/h) | 3600 | 3600 | 3600 | 5400 | 7200 | 7200 | 8800 | 12000 | 12000 | |
| fan power | 195 | 190 | 190 | 150x2 | 190x2 | 190x2 | 700 | 780 | 780 | |
| Interface | Inhale interface (mm) | Φ16 | Φ16 | Φ16 | Φ19 | Φ19 | Φ19 | Φ22 | Φ22 | Φ22 |
| Fluid supplying interface (mm) | Φ12.7 | Φ12.7 | Φ12.7 | Φ12.7 | Φ12.7 | Φ12.7 | Φ16 | Φ16 | Φ16 | |
| Weight (kg) | 87 | 87 | 90 | 107 | 112 | 114 | 177 | 180 | 186 | |
| Dimension | Length (mm) | 1020 | 1020 | 1020 | 1030 | 1030 | 1030 | 1000 | 1000 | 1000 |
|
Width (mm) |
490 | 490 | 490 | 490 | 490 | 490 | 1000 | 1000 | 1000 | |
| Height (mm) | 835 | 835 | 835 | 1290 | 1290 | 1290 | 1470 | 1470 | 1470 | |
| Design condensing temperature (°C) | 45 | |||||||||
Our company has via some certifications,such as ISO9001,ISO14001,CE ,3C and so on.We apply high quality control system components ( compressors, etc ) from famous manufacturers (international and domestic) to our “huaihai” brand commercial series refrigeration equipments. By this way, the entire refrigeration system will be kept stable and reliable. Our products meet the requirements of various national index and have the characteristics of stable quality, good performance, high efficiency, and so on. And thus our products win very good reputation among the users.
