China 3.5-12hp Ccondensing Unit Prices for Cold Room Storage With AC Fan

China 3.5-12hp Ccondensing Unit Prices for Cold Room Storage With AC Fan thumbnail-1
China 3.5-12hp Ccondensing Unit Prices for Cold Room Storage With AC Fan thumbnail-2
China 3.5-12hp Ccondensing Unit Prices for Cold Room Storage With AC Fan thumbnail-3
China 3.5-12hp Ccondensing Unit Prices for Cold Room Storage With AC Fan thumbnail-4
China 3.5-12hp Ccondensing Unit Prices for Cold Room Storage With AC Fan photo-1
China 3.5-12hp Ccondensing Unit Prices for Cold Room Storage With AC Fan photo-2
China 3.5-12hp Ccondensing Unit Prices for Cold Room Storage With AC Fan photo-3
China 3.5-12hp Ccondensing Unit Prices for Cold Room Storage With AC Fan photo-4
US$ 500 - 1,200 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Sanye
Model Number:
HS261CH2
Contact Supplier Request Quote Chat Now
Xuzhou Sanye Refrigeration Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Lianyungang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name Sanye
Model Number HS261CH2
Type Other, Chiller
Application Refrigeration Parts
Certification CE

Specifications

condensing unit prices
1.low noise
2.repadly cooling
3.Energy efficiency
4Use the fan gover

Technical Parameters:

Unit model





HS261CH2

HS263CH3 HS303CH3 HS373CH3 HS453CH3 HS235CH3 HS603DH3 HS753DH3  HS903DH3
Refrigerant    R22
Suitable temperature (℃)             0~15
Power Supply                       220V/50HZ  380V/50HZ  380V/50HZ  380V/50HZ  380V/50HZ   380V/50HZ  380V/50HZ  380V/50HZ  380V/50HZ
Scroll compressor models     C-SB261H5A-3.5hp   C-SB263H8A-3.5hp   C-SB303H8A-4hp   C-SB373H8A-5-hp   C-SB453H8A-6hp   C-SBR235H38A-7hp   C-SC603H8H-8hp   C-SC753H8H-10hp   C-SC903H8H-12hp
The largest operating current (A)        12.9  4.9  5.5  6.6  7.7  8.8  10.6  12.8  15.1
Condenser Fan number  1  1  1  2  2  2  1  1  1
  Air flow (m³/h)  3600  3600  3600  5400  7200  7200  8800  12000  12000
  Power of fan   195  190  190  150*2  190*2  190*2  700  780  780


Connecter

 Inhale interface (mm)   Φ16   Φ16   Φ16    Φ19   Φ19   Φ19   Φ22   Φ22   Φ22
For liquid interface (mm)      Φ12.7   Φ12.7   Φ12.7   Φ12.7   Φ12.7   Φ16   Φ16   Φ16
The weight of unit(kg)    87 87  90 107   112 114  177   180  186
 Size  Length(mm)  1020 1020 1020 1030  1030  1030   1000 1000 1000
   Width(mm)  490  490 490  490  490  490  1000  1000 1000
   Height(mm)  835  835  835  1290  1290  1290  1470 1470 1470
Condensation temperature     45℃

 China 3.5-12hp ccondensing unit prices for cold room storage with AC fanChina 3.5-12hp ccondensing unit prices for cold room storage with AC fanChina 3.5-12hp ccondensing unit prices for cold room storage with AC fanChina 3.5-12hp ccondensing unit prices for cold room storage with AC fanChina 3.5-12hp ccondensing unit prices for cold room storage with AC fan

Why choose us?

1.We are a professional refrigeration manufacturer in china.
2.We are not just partner but also friends
3.we supply the best service and good quality products
4.we have a professional design team and advance technology and world class assembly line


Main components:

compressor : Danfoss scroll compressor , Copeland compressor,lanhai rotary compressor

- 1mm galvanized case,

- fan speed control

- Danfoss spare parts:dual pressure switch,sight glass,drier filter,

- ABB electrical:isolator switch,contactor,time relay,MCB,overload,fault indicator light,

- Liquid receiver with fusible plug from 2-4HP,from 5-6HP with Castel safety release valve,

- Condenser with axial fan motor

- Service valve,

- 3 phase monitoring device

- Low side / high side gauge

- Compressor jacket,

- Suction filter,

- Acoustic lining


Fan speed control

ABB isolator switch,contactor,overload protector,time delay
