2014 new seawater flake ice machine on fishing boat 3000kg/day

Specifications

1.capacity with 20, 30, 40, 50, 60, 70, 85,100, 120, 150Kg etc.
2.CE and ISO approved .Seawater Flake Ice Machine On Fishing Bo

1.It can stop automatically when the ice library is full of ice.

2.Computer detecting, breakdown presenting

3.All stainless steel design, beautiful appearance

4.Famous brand compressor, high quaclity components, stable performance

5.Spray type of making ice of bright and transparent.

6.Widely suitable for restaurants and leisure occasions such as hotel, restaurant, western-style restarant, coffee house, bars, night club, noshery, cold drink shop, etc.

Product Parameters :

Seawater Flake Ice Machine On Fishing Boat



Name	Model number	Size(L*W*H)mm	Power (W)	Power Supply	Volume of ice (KG)
20KG ice making machine	ZBJ-20	300*493*547	180	220V/50HZ	10
30KG ice making machine	ZBJ-30	300*493*547	220	220V/50HZ	10
40KG ice making machine	ZBJ-40	380*543*722	380	220V/50HZ	15
50KG ice making machine	ZBJ-50	380*543*722	350	220V/50HZ	15
70KG ice making machine	ZBJ-70	548*611*883	420	220V/50HZ	25
85KG ice making machine	ZBJ-85	548*611*883	440	220V/50HZ	25
100KG ice making machine	ZBJ-100	548*611*883	460	220V/50HZ	25
130KG ice making machine	ZBJ-130	548*611*883	478	220V/50HZ	25
		635*611*945	685		35
150KG ice making machine	ZBJ-150	548*611*883	720	220V/50HZ	25
		635*611*945			35
200KG ice making machine	ZBJ-200	680*641*1100	805	220V/50HZ	55
300KG ice making machine	ZBJ-300	720*641*1150	1370	220V/50HZ	55

 Note : Customized is accepted .



1)High-quality stainless steel is used for their shells, they are anti-corrosive and durable, and the all-in-one independent structure makes them simple and compact and space-saving.



2)Their boxes are protected with fluorine-free foam thermal cover featuring good insulation effect. Their internal bladders are of fluorine-free bacterial inhibitory-type. They are both energy-saving and environmental friendly.



3)High quality and efficient use of fluorine-free R134a compressors, parts and components have passed relevant safety certifications, and they are safe and reliable.



4)The ice-making process is fully computer controlled, using imported computer chips to make control reliable and operation steady.



5)The use of Italian Haitec two-stage reducer and Korean GGM motor makes noise reduced, operation smooth and reliable. Cooling holes and blower fans are deployed on top of ice makers to ensure that the motor of reducer can operate reliably even under harsh conditions at high temperature.



6)The use of the patented technology,line of chip ice-making chamber separated from the evaporator makes high cooling efficiency and large ice-making capacity.



7)The screw extrusion hob-style ice-making type makes a compact structure, realizing ice and water automatic separation. The optimal design of skate blade makes the shape of ice small and applicable.



8)The unique float-type water tank water inflow system ensures that there is no residual water, no ice clearance process, no water wasting, and makes them water and energy saving.



9)They have ice full display, water deficiency display, overcooling protection display and malfunction warning display, etc. for shutdown protection. The stop automatically in case of ice full or water deficiency and start automatically when power or water supply is resumed. They have automatic reminiscence function.



10)The ice made is small shaped, amorphous granular flake chipped ice, which can infiltrate into narrow space, featuring fast cooling speed, good ice bathing effect. It is specially designed for laboratories.



11)There are power switch and function indicators deployed in the front with detailed instructions. It is intuitive and easy to use. Various safety performance indicators have passed electrical tests, they are safe and reliable.



12)Flake shaped ice is widely used in hospitals, schools, laboratories, research institutes and so on, as well as for food preservation in supermarkets, fishing refrigeration, medical applications, chemical, food processing and other industries. It has wide range of applications.
