Specifications
FeCrAl Alloy resistance wire0Cr27Al7Mo2,0Cr25Al5,0Cr23Al5,0Cr21Al6Nb,0Cr21Al6,0Cr21Al4,0Cr19Al3,0Cr15Al5,0Cr13Al4
size:0.
FeCrAl Alloy resistance wire
0Cr27Al7Mo2,0Cr25Al5,0Cr23Al5,0Cr21Al6Nb,0Cr21Al6,0Cr21Al4,0Cr19Al3,0Cr15Al5,0Cr13Al4
size:0.04mm-10.0mm
ISO9001:2000,ROHS
package:spool and carton
delivery time: within 15 days
payment term:T/T OR L/C
main physical property and chemical composition
main property | type | 0Cr13Al4 | 0Cr21Al4 | 0Cr25Al5 | 0Cr21Al6 | 0Cr21Al6Nb | 0Cr27Al7Mo2 | 0Cr23Al5 |
main chemical composition | Cr | 12-15 | 17-21 | 23-26 | 19-22 | 21-23 | 26.5-27.8 | 20.5-23.5 |
Al | 4-6 | 2-4 | 4.5-6.5 | 5-7 | 5-7 | 6-7 | 4.2-5.3 | |
Fe | rest | rest | rest | rest | rest | rest | rest | |
Mn | <0.7 | <0.7 | <0.7 | <0.7 | <0.7 | <0.2 | <0.7 | |
max working temperature°c | 950 | 1100 | 1300 | 1300 | 1350 | 1400 | 1250 | |
density g/cm3 | 7.40 | 7.35 | 7.10 | 7.10 | 7.10 | 7.10 | 7.25 | |
resistivity | 1.25 | 1.23 | 1.40 | 1.40 | 1.43 | 1.53 | 1.35 | |
melting point °c | 1450 | 1500 | 1500 | 1500 | 1500 | 1520 | 1500 | |
tensile strength | 588-735 | 637-784 | 637-784 | 637-784 | 637-784 | 637-784 | 637-784 | |
elongation% | >16 | >14 | >12 | >12 | >12 | >12 | >12 | |
bending frequency | >5 | >5 | >5 | >5 | >5 | >5 | >5 | |
hardness | 200-260 | 200-260 | 200-260 | 200-260 | 200-260 | 200-260 | 200-260 | |
