Help CenterLarge Grain Dryer
Related Products
Specifications
1.Excellent quality2.Low cost
3.Stability and reliability
4.Simple operation, convenient repair
You can enter product specifications, usage and advantages as well as additional detailed product photos.
Professional drying technology
1. It can improve the drying efficiency.
2. Enhanced lateral eight-slot drying structure makes the grain layer thinner, the grain heating more uniform and the drying effect better.
3. Using constant speed drying method to ensure the grains reduce moisture uniformly during the moisture section.
4. The temperature and moisture will be detected during the whole process, and the grain drying speed will be adjusted automatically. Safe and fast.
5. Using the method of heating around the drying part, it will not be dewed even when the moisture content is high.
6. Large area ventilation, thin-layer drying, large air flow, fast speed.
7. Good fluidity of grains.
8. Low consumption of energy.
9. The hot air channel will not accumulate dust and impurity.
10. The drying part is welded integral structure, even the grain with high moisture content can also have good drying effect.
11. Drying a small amount of grain can also be carried out smoothly.
Three necessary conditions of drying superior grain:
1. The constant-speed drying method which can prevent grain cracking
The control system adjusts the speed of drying and moisture reduction according to the grains’ type and temperature, avoiding grain cracking caused by fast drying
2. The detection method which guarantees the quality of grain
The control system detects grain temperature for real-time, and adjusts the proper temperature of hot air. It avoids grain deteriorationcaused by high temperature, ensures grain quality and germination rate.
3. The moisture content monitoring device which can prevent excessive drying or insufficient drying
The system is equipped with a dedicated online moisture meter, which detects grain moisture in real time dynamically during the drying process, controls the start time of drying accurately, and prevents excessive or insufficient drying.
| Model | 5HGM-25 | |
| Type | Batch type circulation | |
| Volume | Paddy (560kg/m3) | 25.0 |
| Wheat (680kg/m3) | 28.5 | |
| outer dimension (mm) | length × width × Height | 5516 × 4033 × 12542 |
|
Handling capacity(kg/h) (moisture reduction: from 25% to 14.5%) |
1400-2200 | |
Combustion Engine |
type | gum type, high voltage spray |
| ignition method | automatic high voltage ignition | |
| fuel consumption (kg/h) | 20-36 | |
| Fuel | High clean kerosene or high clean 0#diesel | |
| Blower motor power | 5.5 | |
| The total power of Motor(kw) Voltage(v) | 15/380 | |
| Time of feeding (min) | paddy | 22~30 t/h |
| wheat | 22~32 t/h | |
| Time of discharge (min) | paddy | 20~25 t/h |
| wheat | 18~22 t/h | |
| Moisture reduction rate per hour | paddy | 0.6-1.0/% |
| wheat | 0.7-1.1/% | |
| Automatic control and safety device | automatic moisture meter, automatic ignition,automatic stop, temperature control device, fault alarm device, full grain alarm device, electrical overload protection device, leakage protection device | |
