Waterproof ir camera Feature:
Super wide angle (150°)
Automatic heating when the camera's running temperature is below 10°C (optional)
Distance label selectable to be open or closed
Waterproof and weather resistant housing for outdoor use
Excellent night vision
IR distance: approx. 10m
Infrared LED light: 12
Mirror / Normal image switch (depending on the chips)
1 / 4” COLOR CMOS SENSOR SPECIFICATIONS
Image Device:1/4" PC 1030N
TV System: PAL / NTSC
Effective Pixels:648 x 488 pixels
Sensing Area:3.6mm x 2.7mm
Scanning System:2:1 Interlace
Sync. System: Internal
Resolution:420 TV Lines
Minimum Illumination: 0.3Lux (day), 0Lux (with IR)
Microphone: Yes
Video Output:1.0vp-p, 75 Ohm
Gamma Consumption:0.45
AGC: Auto
S/N Ratio: Better than 48 dB
White Balance: Auto
Electronic Shutter:1/50(PAL)/1/60(NTSC)~1/100,000 Seconds
BLC:Auto
Current Consumption:Max. 200 mA
Power Supply: DC 12 V
Connection: RCA / 4 PIN DIN
Anti-vibration:10 g
Operating Temperature:-20°C~70°C, RH 95% MAX.
Storage Temperature:-30°C~80°C, RH 95% MAX.
Lens: f = 2.5 mm, F = 2.0
Lens Angle:120°
Testing Standard: MIL-STD-105E
Tests
Manufacturing Process
Tests
FAQ
Q: What is the MOQ ?
A: 1 peice
Q: How fast for sample delivery?
A: 3-7 days
Q: Can I get a lower price if I order large quantities?
A: Yes, the larger the quantity, the cheaper the prices.
Q: How about the warranty period?
A: One year!
Q: How can you guarantee the quality?
A: Our production quality follows the standard of MIL-STD-105E. We have a QC team with 12 years’ experience. All of the products will run through over 4 times’ 100% testing before being delivered.
