9 Inches Digital Quad Monitor(MO-146D)
Negotiable
MOQ: 3 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Other, car monitor
Voltage:
DC 12V
Car Make:
all kinds
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
5 Inch Digital TFT- LCD Color Weatherproof Car Monitor With Touch ButtonNegotiableMOQ: 3 Pieces -
9 Inch Monitor for Car With Digital PanelNegotiableMOQ: 3 Pieces
-
7 Inch Digital TFT- LCD Color Waterproof Car Monitor With Touch ButtonNegotiableMOQ: 3 Pieces
-
7 Inch Waterproof Digital Color LCD Quad MonitorNegotiableMOQ: 3 Pieces
-
7 Inch TFT LCD Color Digital Car Monitor With Touch Button SystemNegotiableMOQ: 3 Pieces
Type
Other, car monitor
Voltage
DC 12V
Car Make
all kinds
Place of Origin
Guangdong, China
Brand Name
OEM,ODM
Model Number
MO-146D
Product Description
Quad monitor features:
- 9 inches Digital Quad Monitor
- Picture image may be adjusted for Horizontal, Vertical, Mirror and Normal viewing; characters of the menu will not inverse when set to mirror image
- Single, dual, triplex, quad, trefoil, Y-split image and PIP functions available
- System format: NTSC/PAL
- Five trigger lines; once a trigger line is activated, image automatically switches to its corresponding camera. Trigger priority is available
- Auto scan, scan channel and time can be set according to the users' demand
- Reverse warning yardstick
- Touch screen available, can recognize down, left, right side "swipe"; support two-point touch to realize channel switching
- Support level 5 LCD manual backlight adjustment ,level 2 automatic adjustment
- Easy installation and convenient operation, with innovative functions
- Applicable to indoor / outdoor security systems, vehicle and ship surveillance
- 22-Pin:4 AV inputs,1 video output, and 1 audio output
- One VGA image input, resolution: 800 x 600 (60Hz), 640 x 480(60Hz), one VGA audio input
- With touch screen signal output, under the state of VGA display, when it's connected to computer through USB, you can control the computer through the touch screen
9 inches Digital Quad Monitor MO-146D
- 1. Dimension:9”TFT-LCD color digital monitor with built-in quad.
- 2. TV System: NTSC/PAL
- 3. Resolution: 800 x 3(RGB)x480(H)
- 4. Brightness: 400cd/m²
- 5. Contrast: 500:1
- 6. Viewing angle: U:50°/D:70°;R/L:70°
- 7. Aspect ratio: 16:9
- 8. Operating Temperature: -20°C - +70 °C
- 9. Storage Temperature: -30°C - +80 °C
- 10. Power consumption:max.25W
- 11. Power for cameras:max. 4X300mA,12V
- 12. Input voltage:10-32V
- 13. Video inputs:4 video inputs for cameras:peak value:1Vp-p,impedance:75ohm
- 14. Audio inputs:4 audio inputs for cameras:peak value:1Vp-p,impedance:4.7Kohm
- 1 AUX audio input.
- 15. Video outputs:1 REC video output: peak value:1Vp-p,impedance:75ohm
- 1 LIVE video output: peak value: 1Vp-p, impedance: 75 ohm.
- 16. 16.Audio output: 1 LIVE audio input: peak value:1Vp-p,impedance:4.7Kohm
