Help CenterWired/wireless Infrared Smoke & Fire Alarm Sensor Detector YG-04
Related Products
-
Hot 360 Degrees 12V PIR Infrared Microwave Motion Sensor With Plastic Cover (HW-XD02)US$ 5.8 - 6.8MOQ: 2 Pieces -
MCU Control 360 Degree View Wireless Ceiling Infrared Detector (HW-XD02))US$ 5.8 - 6.8MOQ: 2 Pieces
-
360 Degree Angle DC12V Ceiling Infrared PIR Motion Sensor (HW-XD02)US$ 5.8 - 6.8MOQ: 2 Pieces
-
New High Quality New Remote Control Switch RK04S-12-AUS$ 6.58 - 8.25MOQ: 1 Piece
-
Mutifunctional Zigbee Smart Home Gateway Case Zigbee Smart House Security Burglar Alarm System WS1ZUS$ 23 - 30MOQ: 1 Piece
TECHNICAL SPECIFICATION
OPERATING VOLTAGE: 1.AC 220V OR AC 110V(9v back-up battery) 2.9v battery(A 6F22 battery)
STATIC CURRENT: <25uA (AVERAGE VALUE) )
ALARM CURRENT: <3 5mA
BATTERY LIFE: LITHIUM BATTERY WITH LIFETIME 1 YEAR
ALARM INDICATOR: RED LED FLASH
SOUND LEVEL: ≥85dB/3m
WIRELESS RECEIVE/SEND RF: 315 MHz/43 3 MHz
CODING TYPE: 2262
SENDING DISTANCE: 200m(in the open area)
WORKING TEMPERATURE: -10℃~ + ℃
ENVIRONMENTAL HUMIDITY: ≤ 95 %RH
DIMENSION: 128 *38mm
EXECUTE CRITERION: GB471 5-2005; EN1 4606; UL 217
DETECTING AREA: 8 0 square meters when the horizontal height is 6m to 1 2m,60 square meters when the horizontal height is below 6m.The accurate parameters please refer to fire auto- alarm system
design standard GB501 1 6-98
TECHNICAL SPECIFICATION
Adopted MCU auto-processing tchnology, stability improved
Wireless network function
Hush function
Fault auto checking function
Auto reset
Infrared photoelectric sensor
Sound &flash alarm/LED indicator
SMT manufacturetechnology adopted, high stability
Dustproof, mothproof, anti light interference design
Anti-RF interference(20V/m-1 GHZ)
With years of export experience along with excellent quality, advanced services and competitive prices, Shenzhen Eray Electronic Co.,LTD has won numerous customers' trust and support.With years of export experience along with excellent quality, advanced services and competitive prices, Shenzhen Eray Electronic Co.,LTD has won numerous customers' trust and support.
Packing
Gift Box+ Carton Box
Delivery
1. Are you trade company or manufacturer?
We are home alarm systems manufacturer with R & D team.
2. Payment Method: T/T, Western Union, Paypal
3. When can send out sample for quality test?
After received payment, sample will be sent within 3 days and advise tracking number.
4. How many years for warranty?
2 years for alarm systems, 18 months for IP cameras.
