Home > Packaging & Printing > Packing Machinery > Multi-Function Packing Machine > Vertical Automatic Bottle Filling Packing Line

Vertical Automatic Bottle Filling Packing Line

Vertical Automatic Bottle Filling Packing Line thumbnail-1
Vertical Automatic Bottle Filling Packing Line photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Commodity, Food
Packaging Type:
Bags, Pouch
Contact Supplier Request Quote Chat Now
Sol Pack Systems
Payment & Shipping
Payment Methods:
Port of Shipment:
Ludhiana Punjab India
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Beverage, Commodity, Food
Packaging Type Bags, Pouch
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Place of Origin Punjab, India
Brand Name Solpack Systems
Model Number filling packing line
Dimension(L*W*H) 1200x1200x2000mm
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Vertical automatic bottle filling packing line



                           Vertical automatic bottle filling packing line





1.3 Equipment composition and introduction of structure

Composition ——(washing)

——(filling)

——(capping)

——(conveyor transmission)

Body machine ——(electric)

——(electric box)

——(working platform)

——(main transmission)

——(Chain box and entering and exiting arc board)

——(frame)



1.4 Technique characteristics:

Valve quantities of filling: 12 heads

Heads of capping: 1 head

Heads of washing: 12 heads

Capacity: 500ml  2000b/h

         1000ml 1500b/h

1500ml   1000b/h

 Can suits for your different bottle size, we will make corresponding mould for different size bottles.

1.5 Input Power:

Main powerwashing machine: 0.75kw

Main power filling machine: 0.75Kw

Main power capping machine: 0.55Kw

Washing pump:0.37Kw

Filling pump:0.37kw

Cap unscramble: 0.25kw

Working Voltage AC: 380V 50HZ/60HZ, 3 phase.

1.6 Water Consumption: (aseptic water) ≈ 1m3/h

Water Pressure:0.2-0.4 Mpa

1.7 Dimensions of washing machine: LxWxH 1200x1200x2000mm

Weight of washing machine≈800Kg

Dimensions of filling machine: LxWxH 1100x1100x2000mm

Weight of washing machine≈800Kg

Dimensions of capping machine: LxWxH 1000x900x2200mm

Weight of washing machine≈600Kg

Dimensions of conveyor system: LxWxH 1500x1000x800mm

Weight of conveyor system≈150Kg

Picture for automatic washing machine



Vertical automatic bottle filling packing line







Kind Regards
For Sol Pack Systems,
Rattan deep Singh -Export Manager -
Hand Phone # 91 98720-45101, 93178-04252
Skype: lpack
Whatsapp /: 0091-9872045101



 Vertical automatic bottle filling packing line



  Trust us and choose us, We are always trying to do our best and aims to provide our customers with reasonable price and the best service!!!
