Help CenterInkjet Automatic Batch Code and Expiry Date Printing Machine for Bottle
Related Products
Automatic Batch Code And Expiry Date Printing Machine
Interface & Communication:-
7”color screen, along with int’l standard QWERT Keypad
USB Post-easy upgrading; Easy save/restore of text & configfor one or more printer
Ethernet port (10/100MB)
Electronic & Software Features:-
32 digit embedded LINUX operating system
Five processing chip adopted, multi-tasks operstion is available.
User friendly interface, WYSIWYG message/graphic/logo editing.
Storage memory 40MB.
“RUN/STOP” hot key to start and shut down automatically.
“PRINT MENU” hot key to enter printing menu instantly.
Automatic error diagnosis and history saved for maintenance purpose.
USB/Ethernet software automatic upgrading.
Pop-up window to remind changing filters after 2,000 hours running.
Real time and date with calender.
Three print mode: Horizontal-reverse, Vertical-reverse, Negative, Double space, Bold, Character width.
Definfined grid value to move the editing corsors at certain dot.
3 counters & 4 shirts, automatically.
Graphic/logo editing software integrated as standard, full screen.
OPS (Encoder direction recognition and print compensation function).
DMS (Direct Measuring System) using encoder signals (from start of print to next start of print).
Password gives access to different level of users.
Multi operation languages available.
Movie player available, to put training clip in USB disk, for operators (Optional).
Printing Features:-
Expiry date, Batch number, Bar codes (EAN 8/13/128, 2/5_INTERL, CODE 39, 128, ITF_14, 16, UPC8/12, Ext_2/5).
Vertical 48 dots maximum.
Character printing height 1mm~15mm.
6 lines of 7x5 printing, 8lines of 5x5 printing.
Multi-fonts available can be customized upon request max.48 dots vertically.
Direct input Arabic/Chinese/Fares/Russian characters with keypad.
Printing speed (single line):250m/n (5x5), 180m/n (7x5).
Ink Range:-
Full range of inks for alternative application.
Print Head:-
Magnetic shielded print head cover
Ink drop observing magnifier intergrated
Positive air access available, to print ahead to ensure the print head clean, under dusty environment
Valves embedded design
Easily accessable and can be installed at any position
L shape head is available upon request
Nozzle size 55 um standard, 42/70um optional
Distance from print head to print surface 1mm~25mm
Physical features:-
Print house /cabinet :stainlesss steel,IP 54
Umbilical horse /conduit(standard):length 2500mm, diameter 20mm
Printer dimension :?H550mmxW300mmxD320mm
Print head dimension:H180mmxW43mmxD44mm
Gross weight :33.5kg
Power supply :single phase,110v~240v,50/60HZ
Electrical plug:Multiple type available
Working environment temperature:5~45’c(35~100’f
Working humidity:max,90%R.H,non-condesing
Certification /Standard approved:-
T0v/ISO9001
CE(EMC,MD& LVD)
Basic Machine consisting of:-
a) Rottweil I-Jet series Continuous INKJET PRINTERhaving 55/70 micron nozzle with Stainless Steel Cabinet and TFT color screen; graphics and logo editor as standard feature; character height 1mm to 20mm mm and print capability of up-to 6 line printing; automatic error diagnosis and error history saved for maintenance record.
b) Product Detector
c) Print head stand
Note: Electrical Requirement: Single Phase 240V AC, 50c/s, stabilized
And spike free supply
Compressed air: Not needed
Interface & Communication:-
7”color screen, along with int’l standard QWERT Keypad
USB Post-easy upgrading; Easy save/restore of text & configfor one or more printer
Ethernet port (10/100MB)
Electronic & Software Features:-
32 digit embedded LINUX operating system
Five processing chip adopted, multi-tasks operstion is available.
User friendly interface, WYSIWYG message/graphic/logo editing.
Storage memory 40MB.
“RUN/STOP” hot key to start and shut down automatically.
“PRINT MENU” hot key to enter printing menu instantly.
Automatic error diagnosis and history saved for maintenance purpose.
USB/Ethernet software automatic upgrading.
Pop-up window to remind changing filters after 2,000 hours running.
Real time and date with calender.
Three print mode: Horizontal-reverse, Vertical-reverse, Negative, Double space, Bold, Character width.
Definfined grid value to move the editing corsors at certain dot.
3 counters & 4 shirts, automatically.
Graphic/logo editing software integrated as standard, full screen.
OPS (Encoder direction recognition and print compensation function).
DMS (Direct Measuring System) using encoder signals (from start of print to next start of print).
Password gives access to different level of users.
Multi operation languages available.
Movie player available, to put training clip in USB disk, for operators (Optional).
Printing Features:-
Expiry date, Batch number, Bar codes (EAN 8/13/128, 2/5_INTERL, CODE 39, 128, ITF_14, 16, UPC8/12, Ext_2/5).
Vertical 48 dots maximum.
Character printing height 1mm~15mm.
6 lines of 7x5 printing, 8lines of 5x5 printing.
Multi-fonts available can be customized upon request max.48 dots vertically.
Direct input Arabic/Chinese/Fares/Russian characters with keypad.
Printing speed (single line):250m/n (5x5), 180m/n (7x5).
Ink Range:-
Full range of inks for alternative application.
Print Head:-
Magnetic shielded print head cover
Ink drop observing magnifier intergrated
Positive air access available, to print ahead to ensure the print head clean, under dusty environment
Valves embedded design
Easily accessable and can be installed at any position
L shape head is available upon request
Nozzle size 55 um standard, 42/70um optional
Distance from print head to print surface 1mm~25mm
ALL PRODUCTS AND MODELS ARE AVAILABLE:
Hand Phone # 91 98720-45101, 93178-04252
Skype: lpack
Whatsapp /: 0091-9872045101
Trust us and choose us, We are always trying to do our best and aims to provide our customers with reasonable price and the best service!!!
