Specifications
pulse dust collector1.Low resistanceo of the main body
2.High dust elimination efficiency
3.ISO9001:2008
Pulse dust collector
1.Brief introduction
DMC Pulse Dust Collector is a kind of highly efficient collector which is designed on the base of overseas advanced technology. It combines advantage of locellus blowback dust collector and jetting pulse cleaning dust collector, avoids less strength of locellus blowback and simultaneous re-absorbing of jetting pulse cleaning dust and filter. It adopts highly efficient off-line method, so it can clean dust with larger capacity, higher efficiency, lower system resistance, longer life of filter-bag, etc. It is widely used to collect dust in grinder, crusher, packing machine, silo top, matching materials of cement industry. It can clean not only air with common dust, but air with high density (even 1300g/Nm³), so it can collect final product of vertical mill and 0-sepa separator. It can be also widely used in grain, light industry, electric power, chemical industry, metallurgy, etc.
2.Features of DMC Pulse Dust Collector
1. Off-line method cleans dust and dust collecting efficiency can reach 99.99%, there is no second dust absorbing, so it is suitable to deal with smoke with high density, and can directly collect product with high density.
2. Filter material with high quality can meet any working condition.
3. PLC intelligent controlling system can be operated easily, precisely and reliably.
4. Gas tank structure and module manufacturing make installation much easier.
5. Advanced balancing wind design reduces operating resistance of dust collector.
3.The parameters
model |
Total filter area (m2) |
Filtering wind speed (m/min) |
Input air (m³/h) |
No. of filter bag (pc) |
Specification of filter bag (mm) |
Air consumption (m³/h) |
Density of inlet (g/m³) |
Density of outlet (mg/m³) |
DMC-32 |
24 |
1.04-1.67 |
1500-2400 |
32 |
Φ120x2000 |
0.032 |
200 |
50 |
DMC-48 |
36 |
1.15-1.62 |
2500-3500 |
48 |
Φ120x2000 |
0.048 |
||
DMC-64 |
48 |
1.21-1.74 |
3500-5000 |
64 |
Φ120x2000 |
0.064 |
||
DMC-80 |
60 |
1.25-1.67 |
4500-6000 |
80 |
Φ120x2000 |
0.08 |
||
DMC-96 |
72 |
1.27-1.62 |
5500-7000 |
96 |
Φ120x2000 |
0.096 |
||
DMC-112 |
84 |
1.28-1.68 |
6500-8500 |
112 |
Φ120x2000 |
0.11 |
||
DMC-120 |
90 |
1.3-1.76 |
7500-9500 |
120 |
Φ120x2000 |
0.12 |
||
DMC-168 |
126 |
2.54-2.87 |
9500-10500 |
168 |
Φ120x2000 |
0.168 |
4.About Baichy
