Home > Products > New Products > Hot Selling mixing agitator China Supplier
Hot Selling mixing agitator China Supplier
- 50 Set / Sets per Month
- Qingdao Tianjin Shanghai
- T/T Credit Card
Product Details
Condition: | New | Mixer Type: | Agitator | Product Type: | Other, Slurry mixing |
Application: | Other, Liquid with Suspended Solids,Mix drug and slurry | Additional Capabilities: | Granulating | Place of Origin: | Henan, China |
Brand Name: | Baichy | Model Number: | XB series | Max. Loading Capacity: | 30 m3 |
Voltage: | According to model | Power(W): | 1.1-22 kw | Dimension(L*W*H): | According to model |
Certification: | ISO9001:2008 | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
mixing agitator1.Mix ore with chemical agent
2.For froth flotation
3.Easy install
4.ISO9001:2008
Hot Selling mixing agitator China Supplier
1.Brief Introduction Of Reactor Agitator :
Blender For Ore Exploiting is mainly used to mix slurry before flotation in the beneficiation process. It can mix drug and slurry completely. It is suitable to mix slurry with density smaller than 30 % (weight ratio) and size smaller than 1mm. V-belt of motor drives impeller to mix drug and slurry completely. This machine can increase reaction time and strengthen reaction quality of the drug.
2.Product parameter of Reactor Agitator :
Model | Internal diameter (mm) | Internal Height (mm) | Volume (m3) | Impeller speed (r/min) | Impeller diameter (mm) | Weight (t) | Motor power | Dimension (LxWxH) (mm) | |
Model | Power(KW) | ||||||||
XB-500 | 500 | 500 | 0.098 | 600 | 200 | 0.15 | Y90S-6 | 1.1 | 600×566×954 |
XB-750 | 750 | 750 | 0.33 | 530 | 255 | 0.6 | Y90L-4 | 1.5 | 1131×880×1241 |
XB-1000 | 1000 | 1000 | 0.58 | 530 | 255 | 0.99 | Y90L-4 | 1.5 | 1131×1130×1492 |
XB-1200 | 1200 | 1200 | 1.4 | 300 | 400 | 1.05 | Y132S-6 | 3 | 1500×1480×1800 |
XB-1500 | 1500 | 1500 | 2.2 | 320 | 400 | 1.2 | Y132S-6 | 3 | 1750×1640×2190 |
XB-2000 | 2000 | 2000 | 5.46 | 230 | 550 | 1.6 | Y132M2-6 | 5.5 | 2380×2162×2850 |
XB-2500 | 2500 | 2500 | 11.2 | 230 | 650 | 3.44 | Y160L-6 | 11 | 3036×2716×3543 |
XB-3000 | 3000 | 3000 | 19.1 | 210 | 700 | 4.61 | Y225S-8 | 18.5 | 3604×3216×4250 |
XB-3500 | 3500 | 3500 | 30 | 230 | 850 | 7.28 | Y225M-8 | 22 | 3940×3766×5386 |
3.Our Certificate
