Fabric dust collector for grain, cement,granite, grinding, welding plant
Brief introduction of Fabric dust collector for grain, cement,granite, grinding, welding plant
Fabric dust collector is a kind of high efficient collector which is designed on the base of overseas advanced technology. It adopts highly efficient off-line method, so it can clean dust with larger capacity, higher efficiency, lower system resistance, longer life of filter-bag ect. It is widely used to collect dust in grinder, crusher, packing machine, silo top, matching materials of cement industry. It can clean not only air with common dust, but air with high density(even 1300g/nm3), so it can collect final product of vertical mill and 0-sepa separator. It can be also widely used in grain, light industry, electric power, chemical industry, metallurgy, etc.
Woking principle of Fabric dust collector for grain, cement,granite, grinding, welding plant
After dust laden air enters the dust collector, due to sudden expanding airflow end and the role of air distribution plate, some of the large particle falls into hopper because of gravity and inertia;other small and tiny particle comes into filtering chamber, then deposits on media's outer surfaces because of brow-nianmotion and fiber interception. The clean air emerges into the cleaned air chamber and from there it is discharged. The resistance of dust collector increases in accordance with expanding of dust concentration.
When reaching a setpoint, the pulse valve of cleaning system jets a high speed&pressure airflow to clean the sut. That time PLC controls the open&close of the pulse valve. While opening, the compressed air in packet enters theinner of filter cartridge equably, creates immediate pressure and great surge,and dislodges the dust layer falling into container.
Features of Fabric dust collector for grain, cement,granite, grinding, welding plant
- Off-line method cleans dust and dust collecting efficiency can reach 99.99%, there is no second dust absorbing, so it is suitable to deal with smoke with high density, and it can directly collect product with high density;
- Fliter material with high quality can meet any working condition;
- PLC intelligent controlling system can be operated easily, precisely and reliably;
- Gas tank structure and module manufacturing makes installation much easier;
- Advanced balancing wind design reduces operating resistance of dust collector.
Application of Fabric dust collector
Henan Baichy Machinery Equipment Co., Ltd. was founded in 2003.Now it has been becoming a high-tech mining company. Our company integrates research and development, designing, manufacturing, sales and after sales sevices.
The brand products, cone crusher, jaw crusher, impact cursher, sand makeing machine, high efficient fine crusher, high-pressure medium speed mill, vertical mill, micronizer, three-ring mill, ball mill, etc, are in the leading level of the world.
Baichy became the member of "CSSA Chinese gravel Association", and all the products have
gained SO9001: 2008 quality management system certificate and IQNet international certification.
· Enterprise objective: quality first, sustained development.
· Operation concept: focusing on quality, persisting in good faith.
· Operation principle: customer foremost, mutual-win objective.
1.Pre-sale services:
(1) Select equipment model;
(2) Design and manufacture products according to clients’ special requirement;
(3) Train technical personnel for clients.
2.Services during the sale:
(1)Pre-check and accept products ahead of delivery;
(2)help clients to draft solving plans.
3. After-sale services:
(1) Assist clients to prepare for the first construction scheme;
(2) Install and debug the equipment;
(3) Train the first-line operators on site;
