Help CenterSupply BLTB175 Side Breaker Hammer Used for Breaking Stones (hydraulic Breaker) for 40-55 Ton Excavator
Related Products
-
BLTB180S Rock Hammer Breaker Suitable for 44-70 Ton Excavator With High Quality at Reasonable PriceUS$ 1 - 100,000MOQ: 1 Unit -
BLTB180s Rock Breaker Suitable for 44-70 Ton Excavator With High Quality at Reasonable PriceUS$ 1 - 50,000MOQ: 1 Unit
-
Supplying BLTB140 Side Type Hammer Breaker Suitable With High Quality at Reasonable PriceUS$ 1 - 20,000MOQ: 1 Unit
-
BLTB-135T Breaker Hammer With High QualityUS$ 1 - 20,000MOQ: 1 Unit
-
Supplying BLTB70 Power Tools Hammer Breaker Suitable for ExcavatorUS$ 1 - 10,000MOQ: 1 Unit
1.Specification of BLTB175 side type breaker hammer for excavator.
| Model | Chisel Length | Weight | Length | Required Oil Flow | Working Pressure |
Impact Rate |
Hose Diameter |
Applicable Excavator |
| mm | kg | mm | L/min | kg/cm2 | b.p.m | In | ton | |
| BLTB175 | Φ175 | 4200 | 3617 | 210-290 | 160-180 | 200-350 | 1 1/4 | 40-55 |
(It is suitable for 40-55 ton excavator.)
2.Photos of BLTB175 side type hydraulic hammer breaker for excavator
3.Excavator list for BLTB175 side type hydraulic hammer breaker .
BLTB175 side type is suitable Doosan Daewoo DH420, DH500/ Hyundal R505, R430,R455/ Komatsu PC450, PC500/ Hitachi ZX450/ Cat E450 ,E345 / Volvo EC460,EC450 Excavator
4.Advantage for BLTB175 side type hydraulic hammer breaker .
(1) Easy control, friendly used and easy position make it more convenient to excavator work.
(2) The large area of outside bracket can be used to move the broken stones from here to there during working.
5.Payment terms for BLTB175 side type hydraulic hammer breaker .
(1) T/T payment at sight-30% of payment in advance, and 70% of payment before shipment.
(2) With large quantity of goods in stock, we can send goods to customers fastly and short
delivery time
6.warranty period for BLTB175 side type hydraulic hammer breaker . (1) 12 months or (1500 hrs): Cylinder,Piston,Valve, Back head *
(2) 06 month or (1000 hrs): Front head *
(3) 03 month or (500 hrs): Front bush, Brackets *
(4) 01 month or (100 hrs): Chisel Pin, Accumulator *
Note:All the warranty covered from Invoice Date/ Hrs which ever is earlier and must for proper maintenance only*
7.Attention in using BLTB175 hydraulic breaker hammer for excavator.
Do not lift things with the breaker. Lifting materials by hanging wire in the bracket or the chisel not only causes damage to the breaker but also is very dangerous when operating
On a hard and large rock, start breaking at an edge.Even a hard and big rock can be relatively easily broken when hammering begins at a crack or an edge.
Do not allow the breaker to fall to break a rock. Dropping the breaker onto a rock will apply excessive force to the breaker or the base machine, causing damage to many parts of the breaker and the base machine.
Sincerely welcome friends, partners to join us to create a prosperous future.
