High Configuration HDPE Film Corona Treatment Equipment
Corona Treatment Equipment can make the 220V or 380V voltage convert frequency, boost to
more than 10000 V , high frequency high voltage processing high voltage spark discharge to the object
which need to increase the surface adhesion force by specific discharge rack.
Zhengri QF series Corona Machine can process different kinds of refrigerator vacuum food packaging
materials, like LDPE, HDPE, PP, CPP,OPP, Pearlized BOPP, VMCPP etc.
Zhengri QF series Corona machine has two types working voltage 220V/50HZ and 380V/50HZ,
the min power is 1.5KW, the max power is 20KW. The power and function also can be customized.
Plastic film, plastic sheet, plastic parts,aluminum foil, woven fabrics, non-woven fabric, paper, wire,
cable, pipe, plastic sealing strip and textile fiber etc material all have its corresponding corona
treatment equipment.
Advantage
1. It adopts high voltage fast-switching power transistor for invert circuit
2. High efficiency, high operating frequency.
3. Power output is continuous adjustable.
4. Electronic protection and low speed automatic off.
5. Server in the film production, printing, gelatinize, and complex unit.
Technical details
1-Input power: Three phase four wire alternating current 380 v
2-Output Power:0-8000W=4000W*2
3-Output Frequency:16-23KHz
4-Output Voltage:15KV
5-Outline Dimension:H:126cm* W:48cm* L:35cm
6-Weight:80Kg
7-High pressure oil drum extraposition, weight per oil drum : 20kg
8-Outline Dimension per oil drum: H 30cm* W 36cm* L 30cm
9-Suitable Discharge Rack: two rollers less than 300cm
10-Treatment Effect: More than 38 DYN
11-Treating side: Single/Double Side
12- Treating width :10-50m
13- Material Width : 1m-4m Single/double side
14.-Material Thickness :0-4mm
Zhengri Plastic Machine company is set up in 1992. We start our business by manufacturing and developing all
kinds of syringe automatic assembly machine, injection moulding machine, molds, screen printing machine,
pad printing machine, blister packing machine etc. We design and provide the whole syringe production line for
our customers.In recent year we have expand our business scope, start to produce plastic machine, like
Corona treater, Cast film machine, Extruder etc.Our products have been exported to many countries like USA,
Turkey, Egypt, India, Vietnam etc.Our customers are satisfied with our products and service. Most of them are
become our old friends.We aim at provide the best product with best service to our customers.
The warranty period (free maintenance ) is one year, in the first year, all the problems caused by the
machine itself (not human being mistake and force majeure), we will replace the part free of charge,
you should only cover the cost of the engineers out of China. And the rest of the years, we keep
maintenance with only the cost of changed part and engineers. The details will be made by the
agreement.
