DooFlex Offshore Inflatable Pipe Plug
- 5 Piece / Pieces per Month
- Qingdao
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | DooFlex, DOOWIN | Model Number: | TP |
Part: | Other, Pipe plug |
Product Description
DooFlex Offshore Inflatable Pipe Plug
DooFlex offshore inflatable pipe plugs are flow stoppers for temporary close off or seal an opening. Our inflatable pipe plug/stoppers are very suitable for use in pipeline, ducts and tunnels with construction, inspection, repairs, cleaning, and repair, isolate the pipe with outside, the closure for the pipe line.
DooFlex offshore inflatable pipe plugs are constructed of high tenacity, urethane coated nylon fabric. We also make it with other special coating material and synthetic-tire-cord rubber layers. This ensure our inflatable pipe stoppers are resistant to fuel, petro-chemicals, and other caustic chemicals. Each inflatable pipe plug is equipped with rigging hardware, inflation ports, and pressure relief valve.
DooFlex offshore inflatable pipe plugs are multi-size flow stoppers. Each flow stopper can be used to close off a range of pipe-diameter. The inflatable pipe plug are easy to install, and as even more important easy and quick removed because of its light weight.
DooFlex offshore inflatable pipe plugs are available with wide range size. We have various pipe plugger size combination. Diameter is from 0.3m to 5.0m. The standard size is DN100, DN200, DN300, DN400, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200, DN1400, DN1600, DN2000, DN2200, DN2400. Custom sizes, shapes, and configurations can be designed and manufactured to meet special needs.
With their wide range of expansion, their multi-functional capability, their endurance, their long service life and their robustness, the inflatable pipe plugs are the high-performance inflatable stoppers.
DooFlex inflatable pipe plug is extremely cost effective when compare with standard rubber pipe plugs, and efficient way to isolate the pipe. It’s easy to inflate/deflate with ball valves or boat valve option.
Specifications of Offshore inflatable pipe plugs
Model | Lift Capacity | Dimension (m) | Pick Up | 3/4' Inlet | Appr. Packed Size (m) | Weight | ||||
KGS | LBS | Dia | Length | Points | Valve | Length | Width | Width | (kgs) | |
TP-50L | 50 | 110 | 0.3 | 0.6 | 2 | 1 | 0.60 | 0.30 | 0.20 | 5 |
TP-100L | 100 | 220 | 0.4 | 0.9 | 2 | 1 | 0.65 | 0.30 | 0.25 | 6 |
TP-250L | 250 | 550 | 0.7 | 1.1 | 2 | 1 | 0.70 | 0.35 | 0.30 | 8 |
TP-500L | 500 | 1,100 | 0.9 | 1.4 | 2 | 1 | 0.80 | 0.35 | 0.30 | 10 |
TP-1 | 1,000 | 2,200 | 1.0 | 1.8 | 2 | 2 | 1.20 | 0.40 | 0.35 | 18 |
TP-2 | 2,000 | 4,400 | 1.2 | 2.3 | 3 | 2 | 1.10 | 0.40 | 0.40 | 28 |
TP-3 | 3,000 | 6,600 | 1.4 | 2.5 | 3 | 2 | 1.20 | 0.50 | 0.45 | 39 |
TP-5 | 5,000 | 11,000 | 1.5 | 3.4 | 5 | 2 | 1.30 | 0.50 | 0.50 | 52 |
TP-6 | 6,000 | 13,200 | 1.6 | 3.6 | 5 | 2 | 1.35 | 0.50 | 0.50 | 66 |
TP-8 | 8,000 | 17,600 | 1.8 | 3.8 | 6 | 2 | 1.30 | 0.60 | 0.60 | 78 |
TP-10 | 10,000 | 22,000 | 2.1 | 3.6 | 6 | 2 | 1.30 | 0.80 | 0.60 | 89 |
TP-15 | 15,000 | 33,000 | 2.2 | 4.6 | 7 | 2 | 1.30 | 0.80 | 0.70 | 120 |
TP-20 | 20,000 | 44,000 | 2.4 | 5.6 | 7 | 2 | 1.30 | 0.80 | 0.75 | 138 |
TP-25 | 25,000 | 55,125 | 2.5 | 5.7 | 7 | 2 | 1.60 | 0.90 | 0.80 | 189 |
TP-30 | 30,000 | 66,000 | 2.7 | 6.1 | 6 | 2 | 1.60 | 0.90 | 0.80 | 280 |
TP-35 | 35,000 | 77,000 | 2.9 | 6.2 | 6 | 2 | 1.60 | 1.00 | 0.90 | 310 |
TP-50 | 50,000 | 110,000 | 2.9 | 8.0 | 9 | 2 | 1.60 | 1.00 | 1.00 | 340 |
DOOWIN is China leading professional manufacturer of offshore inflatable pipe plugs. The production is controlled under ISO 9001:2008. As per customers' requiremnts, we also can provide the BV etc third party certificate.
Certification of Offshore inflatable pipe plugs
1.Q--- What is the MOQ for offshore inflatable pipe plugs?
A--- 1 piece.
2.Q--- What's payment terms of offshore inflatable pipe plug?
A--- Usually 30% deposit, full payment before shipment.
3.Q--- What is warranty period of offshore inflatable pipe plug?
A--- 12 months
If you have any questions about our offshore inflatable pipe plugs, please do not hesitate to contact us. We are always here for your assistance:)
