v Belt Specification

v Belt Specification photo-1
US$ 0.25 - 18 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Moli
Model Number:
A/B
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANJIN QINGDAO SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin China
Brand Name Moli
Model Number A/B

Specifications

1.high quality
2.long service life
3.small deformation
4.heavy power
5.ISO9001

Raw Edge V-belt

Characteristics:
These belts feature improved transmission efficiency since they are composed of cord and rubber, with side faces made of fabric. Short fibers are mixed in the rubber in the direction of the belt's width, contributing to power transmission and helping to resist abrasion
(caused by side pressure.

Applications: Cars, agricultural machinery, blowers, dynamos, escalators

Belt types:

  1. 1.    Raw Edge Plain Belt (REMF): Standard type
    HM, A, B, BC
  2. 2.    Raw Edge Multiply (MPMF): Low noise type
    HM, A, B
  3. 3.    Raw Edged Cogged V-belts: Flexible, high horsepower type
  • o      RECMF (Applications: passenger cars, trucks, buses)
    Types: HM, A, B, BC, C, CD
  • o      Triplex (Applications: general industrial use)
    Types: AX, BX, CX
  • o      Multi Triplex (Applications: general industrial use)
    Types: RAX, RBX, RCX
  • o      Maxstar Wedge Supreme (Applications: general industrial use)
    Types: 3VX, 5VX
  • o      Multi Maxstar Wedge Supreme (Applications: general industrial use)
    Types: R3VX, R5VX
  • o      Orange Cog (Applications: agricultural machinery)
    Types: LA, LB, LC
  • o      Super Orange Cog (Applications: agricultural machinery)
    Types: LA, LB, LC

Variable Speed Belt

  1. Wrapped type (AGVS)
    Characteristics:
    Wrapped type variable speed belts developed for large-scale agricultural machinery.
    This belt provides enduring the shock and vibration
     caused by the jerky start characteristic of agricultural machinery.

    Applications: Large-scale agricultural machinery

    Belt types: HI, HJ, HK, HL, HM, HN
  2. Raw Edge Cog Type (RCVS)
    Characteristics:
    Continuous variable speed belts with good side pressure resistance and flexibility. High efficient power transmission allows to smoothly follow speed changes, creating excellent acceleration
     response.

    Applications: Gear changers, motorcycles and agricultural machinery.

    Belt types:
    (1) RCVS (Side pressure resistant)
  • For motorcycles
    Types: Top width 10-120 mm
  • For general industrial use gear changers
    Types: Top width 10-120 mm
  • For large-scale agricultural machinery
    Types: HI, HJ, HK, HL, HM, HN

(2) DCVS (Side pressure resistance, high horsepower transmission)
Types: Top width 20-120 mm

Light Duty V-belt

Characteristics:
Good abrasion resistance, with little generation of powder, providing clean power transmission.

Applications: Sewing machines, household electric appliances.

Belt types:

  1. 1.    M Type V-belts: M
  2. 2.    MB Belt: MB, MB-L, DMB, DMB-L

Special Belt

  1. For agricultural machinery
    Hexagonal V-belt

    Characteristics: Multiaxial drive is possible.
    Types: AA, BB, CC


    V rope (Perforated Open end V-belt)
    Characteristics: Belt length can be adjusted by metal fastener.
    Types: M, A, B, C

    V belt with attachment
    Characteristics:
    Due to the special attachment
    on the back face,it can pick up and transfer straw
    Types: A, B

    Belt for vegetable harvesting
    Characteristics:
    Due to the special cushion rubber installed on the back face of the belts, agricultural products are not damaged even when they are transferred by sandwiching them between the belts.
    Types: A, B, C, other



Quality Certificates

v belt specificationv belt specification















About our factory



Our company,WEISHI HONGLI RUBBER CO.,LTD is a specialized manufacturer and exporter of various kinds of rubber products .



 We can design and produce according to your requirements. We have our own tool design, molding and produce department, many years production experience and professional technology can assure the quality and machine ability.

With good reputation from users,our product with trade marks of ''DOUBLE LION'' and ''MOLI'' have been exported to more than ten countries and regions.





If you have any question , please feel free to contact us .

Tel:86-371-86060665

Skype: ling03711







v belt specificationv belt specification
