WSH-50 Groove Contour Mixing Machine
Applications:
The machine,WSH-50 Groove Contour Mixing Machine is a pair of thick liquid mixer of horizontal groove type. It is mainly used in mixing evenly different proportion of dry or wet powdery material in pharmacy industry ,and does not produce the dissolving and volatilizing or gong bad of the supplies in the course of mixing.
It is also suitable for mixing different mainly complementing the material such industrial departments as chemical industry ,food ,etc .it is most suitable for mixing semi-solidly ,solution or gluing and spending big material.
It is an integer seat ,it is flexible and steady mixing thick liquid and part that material keeps in touch with adopts the stainless steel to make for transmission to turn round ,there is the good one that is able to bear causticity ,it can keep the quality of the supplies mixed ,make it not pollute ,and do not change color. The transmission organization adopts worm gear ,worm ,gear wheel transmission mainly ,have good lubrication ,thus improving the service life of the machine.
It adopts the electric equipment to control manipulation ,easy and simple to handle ,adopts pouring the material automatically, which have relieved the operator intensity.
Main technical data:
Model |
WSH-50 |
WSH-200 |
WSH-300 |
WSH-400 |
|
Trough Capacity (L) |
50 |
200 |
300 |
400 |
|
Capacity Max(mm) |
150 |
320 |
380 |
400 |
|
Mixing speed(r/min) |
25 |
26 |
26 |
26 , 32 |
|
Assistant Mixing speed(r/min) |
33 |
19 |
19 |
16 , 20 |
|
Mixer trough upturn angle |
115° |
115° |
115° |
115° |
|
Motor power(kw) |
Mixing |
4 |
4 |
4 |
7.5 |
Trough |
0.75 |
0.75 |
1.1 |
1.1 |
|
Export standard plywood package are supplied with well packed. we can make the packages according to customer's request. Sea packages or Air packages are both available.
Usually to ship WSH-50 Groove Contour Mixing Machine by sea way.
Our Company is one famous group and apply itself to R&D,manufacture machinery for Pharmaceutical, Chemical, food and so etc fields.
Our Main Products are: Tablet press,Mixer,Crusher,Granulator,Dryer,Coater,Packing machine,Filling Machine,Miller and Pulverizer, Feeder,Oven, Deduster, Dust Collector, vibration sieves...
We also supply punch die sets and spare parts in standard or not.
