RC- 3 dissolution testing equipment

Specifications

RC- 3 dissolution testing equipments are detecting velocity and extent of pharmic dissolution from tablet,capsule etc
CE&GMP

 RC- 3 Dissolution testing equipment

The Series of instruments are used for detecting velocity and extent of pharmic dissolution from tablet ,capsule etc in prescriptive menstruum

Applicable standards:
1. National standard (Chinese codex)/2000/
2. Crporate standard (Dissolution tester)Q/12XQ0187-2004

Features:
1. It has three vessels and three poles ,arranged on one line ;
2. The head part of the instrument can be artificially turned over smoothly and flexibly .
3. The basket units and paddle units are made of imported stainless steel (ss316L)
4.The magnetism-pumped circular water current can heat the system evenly ,and the bath liquid can achieve an equal temperature.
5.A MPU is used in dissolution tester to automatically control the temperature,rotational speed and time ,and the parameters can be preset ant any time .
6. It can be operated conveniently by keystroke, The measurement result is displayed by LED ,The preset and real data can be displayed alternately in time .
7. Automation :Auto-set ,auto=diagnose ,auto-alarm.



Specifications:

Speed range	(20-200)rpm
Speed accuracy	±2rpm
Temperature Range	ambient to +39.9°C
Temperature Stability	±0.3°C
Automatic time range	(5-900)min
Time accuracy	±0.5min
Paddle radial run-out	±0.5min
Basket radial run-out	±0.1min
Power	220v/50HZ/1000W or 110v/60HZ/1000W
Dimension	(510×300×480)mm
Weight	35KG







Service

A. To pick up machine more easy & correct.

First, We need client to provide below information about their product:

1) The requirement of raw material: we require powder or grains with good fluidity & dry, can fall down from cone charging barrel.

2) We need know the size, shape of tablets / pills. Yield(capacity) in your request.

So we can figure out if our machine can compress and which models will meeting with your requirement.

B. We can design, customize and make dies for customers.
