pesticide and coating dispersering equipment
US$ 500 - 10,000
/ Set
1 Set(Min. Order)
- Shanghai
You May Like
Product Details
| Condition | New | Mixer Type | Other, disperser | |
| Product Type | Paint | Application | Liquid | |
| Additional Capabilities | Coating | Place of Origin | Shanghai, China | |
| Brand Name | ELE | Model Number | EBF | |
| Voltage | customized | Power(W) | customized | |
| Certification | CE,ISO | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Pesticide and Coating Disperser
| Model | EBF Coating Disperser | ||||||
| Voltage/Frequency | 380v, 3PH,50Hz, ( can be customized) | ||||||
| Frequency Control | with inverter( Kongkong-TTK), can adjust speed steplessly | ||||||
| Motor | Siemens or ABB | ||||||
| Stirrer | dispersing disc,once forming,zig-zag type and it is 45° angle | ||||||
| Processing Capacity | 50-500L ( water as medium) | ||||||
| Lifting Method | hydraulic lift | ||||||
| Material | the part contact with the materials is SS304,316L ( can choose according to your PH) | ||||||
| Application | Paint,Fuel,Ink,Papermaking,medicine,chemical industry, etc. to mix and blend more than two kind of liquid and powder solids. | ||||||
| Features | 1.suitable for all kinds of liquid to premix,disperse and color matching. | ||||||
| 2.it can process different kind of viscosity and capacity | |||||||
| 3.variable speed control with inverter | |||||||
More Detail Parameters
| Model | Main Power/kw | Rotation rpm | Disc Diameter /mm | Stroke/mm | Pump Power/kw | Weight/Kg | Lognth/ mm | Height/m | Centre Distance /mm |
| EBF-4 | 4 | 1400 | 100-200 | 700 | 0.75 | 700 | 1400 | 1420 | 580 |
| EBF-7.5 | 7.5 | 1400 | 200-300 | 900 | 1.1 | 1000 | 1650 | 1850 | 765 |
| EBF-11 | 11 | 1400 | 200-300 | 900 | 1.1 | 1000 | 1650 | 1850 | 765 |
| EBF-15 | 15 | 1400 | 200-300 | 900 | 1.1 | 1000 | 1800 | 1850 | 915 |
| EBF-18.5 | 18.5 | 1250 | 300-400 | 1200 | 2.2 | 1500 | 1800 | 2120 | 1100 |
| EBF-22 | 22 | 1250 | 300-400 | 1200 | 2.2 | 1500 | 2360 | 2120 | 1250 |
| EBF-37 | 37 | 1250 | 300-400 | 1200 | 2.2 | 1800 | 2520 | 2120 | 1400 |
| EBF-45 | 45 | 1250 | 400-500 | 1500 | 2.2 | 1800 | 2830 | 2750 | 1400 |
| EBF-55 | 55 | 1250 | 400-500 | 1500 | 2.2 | 2000 | 2830 | 2750 | 1500 |
Remarks
1.If oil product, the motor can be explosion-proof, with on-spot expolsion-proof control box.
2. The machine can be customized according to practicle condition and specific requirment.
For more information and problems, pls feel free to contact with our sales engineer.
Tel:86-21-65444615
Mobile:+86 18019236593
Fax:86-21-55387553
Skype:Edwinzhang9
