Liquid Dispersion Machine
- 200 Set / Sets per Month
- Shanghai
You May Like
Product Details
| Mixer Type | Agitator | Application | Liquid | |
| Additional Capabilities | Coating | Place of Origin | Shanghai, China | |
| Brand Name | ELE | Model Number | EBF |
Product Description
Specifications
1.liquid dispersion machine2.high speed disperser
3.high speed dissolver
4.high speed mixer
5.mixing machine
EBF Liquid Dispersion Machine
The high speed disperser suitable for batch production, it is apply to all kind of liquid to pre-mix, disperse, color matching, etc.
Features:
- hydraulic lifting, the frame can turn around flexible
- can match with cover, incase of material splashing or flying and volatilization of solvent based product during working.
- less air absorption during working
- it can blend and dissolve product quickly
- with inverter, various speed control, low noise and long-time continuous production
- stable performance, high efficiency
- stainless steel mixing tank with clamp or belt is optional
- motor can be explosion-proof, and the dispersing tank can be vacuum or seal
- it can be hydraulic lift or pneumatic lift
- Type: floor type and platform type
- one machine can serve several tanks
More Detail Parameters
Model | Main Power (kw) | Rotation Speed (rpm) | Diameter of Disc (mm) | Stroke (mm) | Pump Power (kw) | Weight (kgs) |
EBF-4 | 4 | 1440 | 100-200 | 700 | 0.75 | 700 |
EBF-7.5 | 7.5 | 1440 | 200-300 | 900 | 1.1 | 1000 |
EBF-11 | 11 | 1440 | 200-300 | 900 | 1.1 | 1000 |
EBF-15 | 15 | 1440 | 200-300 | 900 | 1.1 | 1000 |
EBF-18.5 | 18.5 | 1250 | 300-400 | 1200 | 2.2 | 1500 |
EBF-22 | 22 | 1250 | 300-400 | 1200 | 2.2 | 1500 |
EBF-37 | 37 | 1250 | 300-400 | 1200 | 2.2 | 1800 |
EBF-45 | 45 | 1250 | 400-500 | 1500 | 2.2 | 1800 |
EBF-55 | 55 | 1250 | 400-500 | 1500 | 2.2 | 2000 |
Remarks
1.The motor can be explosion-proof
2. we can customize according to different requirement.
