Help CenterProfessional Stainless Steel Shampoo Making Machine
Related Products
Specifications
1.Shampoo Making Machine2.precision stator and rotor
3.ss304/ss316L
4.speed:0-3000rpm
5.hydraulic lift or pneumatic lift
Shampoo Making Machine, High shear Homogenizer, Batch High Shear Homogenizer, High Shear Homogeneous Mixing Machine, Emulsion Machine
Description
High Shear Homogenizer is the key product of ELE and the unique, precise emulsification working head is the key point to homogenizing effect. The precision between stator and rotor is composedof factors such as space force, concentricity, material hardness, shearing area, linear velocity etc..Homogenizer are widely used in chemical production, liquid with liquid, liquid with powder.
With high emulsifying efficiency, processing time gets quite shorter.
Feature
1. Precise combination between stator and rotor for our mulsers;
2. Fine forging for stator and rotor, linear cutting form, claw type structure, two-way suction, high efficiency for circulation, no dead corner for ELE emulsion machines;
3. Ideal gap between rotor and stator, advanced processing effect, shorter working time
4. Special heating treatment for stator and rotor, the surface wear-resistance is 2 to 3 times than the ordinary stainless steel;
5. Claw style structure, drawing material from the bottom of tank into the centre of working head because the centrifugal force speeds up toward the side of working head;
6. CNC( numerical control machine) makes higher accuracy for the space between stator and rotor and more stable for the gravity;
7. The key parts are processed via fine grinding to make that the combination between stator and rotor reach American Standards.
8. The dynamic and static balance test for the rotating part to make sure the stability at the condition of high speed rotation for the emulsifying machine, lower noise to prolong the working life of high shear homogenizer
9. Ex-proof motor(option)
10. Style: Hydraulic Lift or Pneumatic Lift
Technical Parameters
| Model | Shampoo Making Machine | ||||||
| Power Supply | 380v, 50Hz,three phase ( can be customized) | ||||||
| Capacity | 10L-10000L | ||||||
| Rotation Speed | 0-3000rpm | ||||||
| Speed Adjustment | with inverter(various speed control) | ||||||
| Lifting method | Pneumatic lift or hydraulic lift | ||||||
| Features | 1.the stator and rotor is after special heat treatment and precision forging | ||||||
| 2.the material of the stator and rotor is ss304, 316L stainless steel | |||||||
| 3.the rotation part is after dynamic and static balance test, low noise, prolong the service life. | |||||||
| 4. the surface is after special treatment, advance the abrasion resistance. | |||||||
| 5.claw structure, two-way suction, linear cutting. good circulation, without dead corner | |||||||
| 6.mixing tank is able to achieve heating or cooling, vacuum | |||||||
More Parameters
| Model | Power /KW | suggested capacity/L | Rotation/rpm | H(mm) | A(mm) | B(mm) | C(mm) |
| EBR-1.1 | 1.1 | 10-50 | 3000 | 455 | 90 | 100 | 200 |
| EBR-2.2 | 2.2 | 20-100 | 3000 | 510 | 120 | 120 | 250 |
| EBR-4 | 4 | 30-200 | 3000 | 660 | 135 | 120 | 250 |
| EBR-7.5 | 7.5 | 200-500 | 3000 | 780 | 150 | 120 | 300 |
| EBR-11 | 11 | 300-800 | 3000 | 946 | 165 | 150 | 350 |
| EBR-15 | 15 | 300-1200 | 1500/3000 | 970 | 180 | 150 | 350 |
| EBR-18.5 | 18.5 | 300-1800 | 1500/3000 | 1035 | 200 | 150 | 350 |
