Home > Manufacturing & Processing Machinery > Mixing Equipment > Mixing Tank > Inline Homogenizing Pump

Inline Homogenizing Pump

US$ 500 - 100,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Product Type:

Perfume

Place of Origin:

Shanghai, China

Brand Name:

ELE

Contact Supplier Request Quote Chat Now

Shanghai ELE Mechanical & Electrical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Product Type Perfume

Place of Origin Shanghai, China

Brand Name ELE

Model Number ELR/3

Specifications

1.good appearance
2.precision finishing stator and rotor
3.rotation:2890rpm
4.flow 0.5-70m3/h
5.head/lift 8m

ELR/3 Stator and Rotor

Stator and rotor(Inline high-shear Homogneizer), with precision stator and rotor,widely used in the area of bitum emuslion, modified asphalt emulsion, food, beverage, diesel emulsion, etc.

Features:

The grinding cavity is consists of three groups of stator and rotor (2 layers, 4 layers and 6 layers), highly working accuracy, large capacity and wide viscosity, more suitble for industrial on-line production.
High shear emulsion pump is best emulsifying effect and top efficiency, more suitable for production which need high requirement for emulsifying, then it is the first choice for the micro-emuslion production.
According to your PH, there are materials of ss304 and 316L for your choice.
Adopting double mechanicial seal also can configure water protector
It is elastic connection, low noisy and table performance.
It can design jacket for cooling and heating.

Technical Parameters

Model	Power (kw)	Rotation Speed (rpm)	Flow (m3/h)	Entrance (mm)	Exit (mm)
ELR401/3	1.1/1.5	3000	0.5	DN40	DN32
ELR405/3	4	3000	2	DN40	DN32
ELR410/3	7.5	3000	4	DN50	DN40
ELR415/3	11	3000	6	DN60	DN50
ELR420/3	15	3000	12	DN60	DN50
ELR425/3	18.5	1500/3000	16	DN60	DN50
ELR430/3	22	1500/3000	18	DN60	DN50
ELR450/3	37	1500	26	DN100	DN80
ELR460/3	45	1500	30	DN125	DN100
ELR475/3	55	1500	32	DN125	DN100
ELR490/3	75	1500	45	DN125	DN100
ELR510/3	90	1500	55	DN125	DN100
ELR530/3	110	1500	70	DN150	DN125
