Help CenterFine Grinding and Dispersing for Basket Mill
Related Products
Specifications
1.apply in paint, ink,pigment2.mixing & grinding together
3.easy to change material
4.without dead corner
5.high effecience
Hydraulic Lift Basket Mill, Pneumatic Basket Mill
Description
Our basket mill is a kind of wet grinding machine, it integrates pre-disperse, fine griding and eventually spread into one machine. It is widely used in paint,coating, color paste, dye, etc.
Working Principle
With dispersion disc and beads mill complex structure, basket mill integrates high speed dispersing and superfine wet-grinding in the same machine. Dispersing disc speed up the particle wetting and contribute dispersion effect, so high viscosity materials can be dispersed rapidly for high speed running of dispersion disc.
Features
1, no need using of pump, pipe, valve, other tank, and thus no leftover, large output
2, low cost, high efficiency, short processing time
3, one machine can process kinds of materials, users can change to produce different products and colors.
4, flexible operation, one worker can operate several basket dispersing mills.
5, hydraulic lifting
6. High chrome steel for the basket with high wear-resistant
7. Two directional absorbing the materials
8. For the bearing structure, most of suppliers adopt tin bronze or lubricated bearing, which wears down very easily within the paste including particle.
Generally speaking,it needs to change another one after a few months' usage, that is costy and troublesome.
In order to avoid this problem to make sure the stability of the high speed rotation for the basket and high wear resistance for the bearing,
ELE develops a new structure non-bearing structure for the basket mill, which has long working life.
Two-way absorb charge way
Technical Parameters
Model |
Chamber Volume (L) |
Power (kw) |
Speed (rpm) |
Capacity (L) |
Media size (mm) |
Stroke (mm) |
EBM-4 |
3.6 |
4 |
0-3000 |
<120 |
1.8-2.4 |
800 |
EBM-7.5 |
4.9 |
7.5 |
0-1500 |
<200 |
1.8-2.4 |
900 |
EBM-11 |
6.6 |
11 |
0-1500 |
<260 |
1.8-2.4 |
900 |
EBM-15 |
9.1 |
15 |
0-1500 |
<350 |
1.8-2.4 |
900 |
EBM-18.5 |
17.2 |
18.5 |
0-1500 |
<500 |
1.8-2.4 |
1100 |
EBM-22 |
20.1 |
22 |
0-1500 |
<800 |
1.8-2.4 |
1100 |
EBM-30 |
32.3 |
30 |
0-1500 |
<1200 |
1.8-2.4 |
1100 |
EBM-37 |
39.2 |
37 |
0-1500 |
<1500 |
1.8-2.4 |
1600 |
EBM-45 |
52.3 |
45 |
0-1500 |
<2000 |
1.8-2.4 |
1600 |
EBM-75 |
85.4 |
75 |
0-1500 |
<3000 |
1.8-2.4 |
1800 |
Basket Structure
