MSATA Mini PCI SSD

Name: MSATA Mini PCI SSD
Brand: KingDisk
SKU: 125945025
Availability: InStock

Shenzhen Kingdisk Century Technology Co., Ltd.

Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Products Status:

Stock

Application:

Other, motherboard with Mini PCIe socket

Type:

Internal

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Application Other, motherboard with Mini PCIe socket

Type Internal

Style SSD

SSD Capacity 64GB

Size Other, 30mmX50mm or 30mmx70mm

Interface Type Other, Mini-PCIe

Speed Other, N/A

Cache Other, N/A

Brand Name KingDisk

Model Number SSD-KD-mSATA.H-MJ5

Place of Origin Guangdong, China

Specifications

1.mSATA Mini PCI SSD
2.Max Read:97MB/s *Max Write:53MB/s
3.Capacity:4GB-64GB
4.CE,FCC,RoHS
5.With 2 years warranty

SSD-KD-MSATA.H-MJ5
Item	Model	SSD-KD-MSATA.H-MJ5
	Interface	SATAⅡ
Performance	Capacity(GB)	8GB(2CH)	16GB(4CH)	32GB(4CH)	64GB(4CH)
	Sustained Read	77MB/S	143MB/S	150MB/s	152MB/S
	Sustained Write	15MB/S	27MB/S	58MB/s	65MB/S
	Random IOPS	6K
	Average Access time	0.2ms
Storage Media	NAND Flash	MLC
Power Consumption	input Voltage	3.3V+/_5%
	Idle	0.5W
	Active	2.0W
Reliability& Endurance	Write endurance	8years @100GBytes write and erase per day at 32GB
	Read endurance	unlimited
	Wear-Leveling Algorithm	Dynamic and static wear-leveling
	Data Retention	10years at 25ºC
	MTBF	1,000,000hours
	ECC	support NCQ,TRIM 16bits or 24bits in 1024 bytes
	Bad Block Management	Auto Bad Block Management in system
Environment	Operating Temperature	0~70°C
	Non-operating Temperature	-40~85°C
	Ambient Humidity	5-95%
Warranty	2years
Available unit	Available	NO EOL
Testing Platform	CPU:Intel® Core™ i3 Duo CPU 540 @ 3.07GHz Chipset:Intel® H55 Express Chipset Memory:Kingston KVR800D2N5/2G OS:Microsoft Windows 7 Professional 64-bit AHCI Driver:Intel® Rapid Storage Technology – Intel® ICH10R SATA AHCI Controlle v9.6 BIOS Settings: AHCI Mode
Testing Software	ATTO Disk Benchmark,CrystalDiskMark v3.0 ,HD Tach RW 3.0.1.0,HD Tune PRO 3.50
Physical Dimensions & Weight	Height(mm)	3.5+/_0.25
	Width(mm)	30+/_0.25
	Length(mm)	23.5+/_0.25
	Weight(g)	3.5+/_0.5
The read and write speed is limited to this test platform.
