IDE Disk 3.5

Name: IDE Disk 3.5
Brand: KingDisk
SKU: 125944545
Availability: InStock

US$ 100 - 610 MOQ: 10 Pieces

Key Specifications

Products Status:

Stock

Application:

Laptop

Type:

Internal

Shenzhen Kingdisk Century Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Application Laptop

Type Internal

Style SSD

SSD Capacity Other, 8GB-256GB

Size Other, 3.5"

Interface Type IDE

Speed Other

Brand Name KingDisk

Model Number SSD-KD-PA25-MJ

Place of Origin Guangdong, China

Specifications

1.IDE disk 3.5
2.Max up to:93MB/s/77MB/s
3.warranty 2 years

General
Product model	SSD-KD-PA25-MJ
Size	3.5"
Interface	PATA(IDE44Pin)
Storage media	MLC-NAND Flash
Performance
Capacity(GB)	8GB(2C) 16GB(8C) 32GB(8C) 64GB 128GB 256GB
Max Sustained Read	57MB/s 78MB/s 92MB/s 92MB/s 91MB/s 93MB/s
Max Sustained write	29MB/s 50MB/s 53MB/s 77MB/s 76MB/s 77MB/s
Random IOPS	6325
Average Access time	0.2ms
Power Consumption
input Voltage	5V±5%
Work power	Max 1.8W
Standby power	Max 0.7W
Reliability& Endurance
Write endurance	8years@100GBytes write and erase per day
Read endurance	unlimited
S.M.A.R.T	Support
Wear-Leveling Algorithm	Dynamic and static wear-leveling
Data Retention	10years at 25ºC
MTBF	1,000,000hours
ECC	Supports BCH ECC 8bits or 15bits in 512 bytes
Bad Block Management	Auto Bad Block Management in system
Environment
Operating Temperature	0~70°C
Non-operating Temperature	–45~85°C
Shock	2,000G(0.3ms half sine wave)
Vibration	20G(40-2000HZ)
Humidity	5-95%
Physical Dimensions & Weight
Height(mm)	9.5mm
Width(mm)	70mm
Length(mm)	100mm
Weight(g)	75±0.5g
Testing software&platform
Testing Software	HDBench3.4.0.3, IOMeter 2010.5.14
Testing Platform	CPU:AMD Athlon 64×2 5200+ 2.7GHz,SDRAM:DDR2 800(PC6400) 2048 MB×1PCS, Mainboard:AMD RS780 (ATI Radeon HD 3200 Graphics)System:Microsoft Windows XP Professional SP2
