1.8 Micro SATA Hard Drive

Specifications

1.8 Micro SATA hard drive
Support NCQ,SMART
Density: 8GB-128GB
Support static and dynamic wear-leveling, bad block management

SSD-KD-MS18-MJ5
Item	Model	SSD-KD-MS18-MJ5
General	Form factor	1.8"
	interface	MicroSATA
Performance	Capacity(GB)	8GB(2C)	8GB(4C)	16GB(4C)	16GB(8C)	32GB(8C)	64GB(8C)	256GB(8C)
	Sustained Read	72MB/S	92MB/S	92MB/S	184MB/S	92MB/S	92MB/S	92MB/S
	Sustained Write	46MB/S	72MB/S	72MB/S	72MB/S	72MB/S	76MB/S	72MB/S
	Random IOPS	6325
	Average Access time	0.2ms
Storage Media	NAND Flash	MLC-NAND Flash
Power Consumption	input Voltage	3.3V or 5V± 5%
	Idle	0.5W
	Active	2.0W
Reliability& Endurance	Write endurance	80years@10GBytes write and erase per day
	Read endurance	unlimited
	Wear-Leveling Algorithm	Dynamic and static wear-leveling
	Data Retention	10years at 25ºC
	MTBF	1,000,000hours
	ECC	Supports BCH ECC 8bits or 15bits in 512 bytes
	Bad Block Management	Auto Bad Block Management in system
Environment	Operating Temperature	0~70ºC
	Non-operating Temperature	-40~85ºC
	Shock	2,000G(@0.3ms half sine wave)
	Vibration	20G(40-2000HZ)
	Humidity	5-95%
Warranty	2years
Available unit	Available,NO EOL
Testing Platform	AMD Athlon 64 3000+ 1.8GHz,DDR2 PC2-5300 512MB×2pcs double channel. RAM,NVIDIA nForce520 chipset,Microsoft Windows XP Professional SP3
Testing Software	HDBench3.4.0.3, IOMeter 2006.07.27
Physical Dimensions& Weight	Height(mm)	5.0± 0.25
	Width(mm)	54± 0.25
	Length(mm)	78± 0.25
	Weight(g)	60
The read and write speed is limited to this test platform.
