SATA II 3Gb/s Half Slim SSD

FOB Price

Negotiable / Piece

50 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1.SATA II 3Gb/s Half-Slim SSD
2.Max Read:165MB/s *Max Write:145MB/s
3.Capacity:4GB-128GB
4.CE,FCC,RoHS

General
Product model	SSD-KD-SA18.H-MJ
Size	half slim
Interface	SATA II
Storage media	MLC-NAND Flash
Capacity(GB)	4GB 8GB 16GB 32GB 64GB 128GB
Performance
Max Sustained Read	165MB/s
Max Sustained write	145MB/s
Random IOPS	7500/7000
Average Access time	0.2ms
Power Consumption
input Voltage	5V±5%
Work power	Max 1.5W
Standby power	Max 0.5W
Reliability& Endurance
Write endurance	8years@100GBytes write and erase per day
Read endurance	unlimited
S.M.A.R.T	Support
WearLeveling Algorithm	Dynamic and static wear-leveling
Data Retention	10years at 25ºC
MTBF	1,000,000hours
ECC	Supports BCH ECC 8bits or 15bits in 512 bytes
Bad Block Management	Auto Bad Block Management in system
Environment
Operating Temperature	0~70°C
Non-operating Temperature	–45~85°C
Shock	2,000G(@0.3ms half sine wave)
Vibration	20G(40-2000HZ)
Humidity	5-95%
Physical Dimensions & Weight
Height(mm)	5mm
Width(mm)	39mm
Length(mm)	54mm
Weight(g)	8
Testing software&platform
Testing Software	HDBench3.4.0.3, IOMeter 2006.07.27
Testing Platform	AMD Athlon 64 3000+ 1.8GHz,DDR2 PC2-5300 512MB×2pcs double channel RAM,NVIDIA nForce520 chipset,Microsoft Windows XP Professional SP3
