Hot-sale 8GB 40pin IDE DOM for Vending Machine

Name: Hot-sale 8GB 40pin IDE DOM for Vending Machine
Brand: KingDisk
SKU: 125941591
Availability: InStock

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Products Status:

Stock

Application:

Other, kiosk,vending machine etc.computer terminal

Type:

Internal

Shenzhen Kingdisk Century Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Application Other, kiosk,vending machine etc.computer terminal

Type Internal

Style SSD

SSD Capacity 8GB

Size Other, 23.5 X6.8 X60mm

Interface Type IDE

Speed Other, N/A

Cache Other, N/A

Brand Name KingDisk

Model Number DOM-KD-PA40L.1-SS

Place of Origin Guangdong, China

Specifications

1.100% original
2.all brands can supply
3.Capacity:2GB-32GB
4.CE,FCC,RoHS
5.With 3 years warranty

General
Product model	DOM-KD-PA40L.1-SS
Interface	40PIN IDE Socket
Storage media	SLC-NAND Flash
Capacity(GB)	1GB 2GB 4GB 8GB 16GB 32GB
Performance
Max Sustained Read	29MB/s 30MB/s 28MB/s
Max Sustained write	23MB/s 24MB/s 15MB/s
4KB Sequential Read IOPS	4311
4KB Sequential Write IOPS	647
Average Access time	0.2ms
Power Consumption
input Voltage	3.3v/5v
Work power	0.45W
Standby power	0.0005W
Reliability& Endurance
Write endurance	8years@100GBytes write and erase per day
Read endurance	unlimited
S.M.A.R.T	Support
Wear-Leveling Algorithm	Dynamic and static wear-leveling
Data Retention	10years at 25ºC
MTBF	1,000,000hours
ECC	Supports BCH ECC 8bits or 15bits in 512 bytes
Bad Block Management	Auto Bad Block Management in system
Environment
Operating Temperature	0~70°C
Non-operating Temperature	–45~85°C
Shock	2,000G(@0.3ms half sine wave)
Vibration	20G(40-2000HZ)
Humidity	5-95%
Dimensions
Height(mm)	23.5mm
Width(mm)	6.8mm
Length(mm)	60mm
Weight(g)	11g
Testing software&platform
Testing Software	HDBench3.4.0.3, IOMeter 2010.5.14
Testing Platform	CPU:AMD Athlon 64×2 5200+ 2.7GHz,SDRAM:DDR2 800(PC6400) 2048 MB×1PCS, Mainboard:AMD RS780 (ATI Radeon HD 3200 Graphics) System:Microsoft Windows XP Professional SP2
