Specifications
KingDian 9pin e usb DOMMOQ:1pcs,Samples.
Factory Price
Transfer Rate:60MB/s
ECC (Error Correction Code): 8/16-bit/512Bytes
Product Name : Brand New e USB DOM , KingDian 9pin e usb DOM 2GB
Model: DOM-KD-USB-MU
Capacity Ranges: 1-32GB
Transfer Rate : 60MB/S
DOM Series: Disk On Module, is a high-performance, embedded flash drive designed to replace the traditional IDE mechanical hard drives. It is mainly used in some old motherboards, to enhance the performance of the equipment. It is characterized by the relatively small size, safe and reliable. DOM has a small control chip firmware, transfer data by standard interface of IDE, SATA, USB, no need additional host software.
DOM work at the voltage of 5V, it provided the scalability new features, such as more cost-effective designs, better performance, improved reliability, making it ideal for the field of embedded memory. PATA DOM supports the standard ATA / IDE, up to PIO Mode-4, Multiword DMA Mode 2 and Ultra DMA Mode-6, compatible with all the major operating systems on the market, such as the Microsoft Windows series, Mac OS, and Unix versions.
| DOM-KD-SA.4-MJ5 | |||||||||
| Item | Model | DOM-KD-SA.4-MJ5 | |||||||
| General | interface | SATA | |||||||
| Performance | Capacity(GB) | 1GB(1CH) | 2GB(1CH) | 2GB(2CH) | 4GB(2CH) | 8GB(2CH) | 8GB(4CH) | 16GB(4CH) | 32GB(4CH) |
| Sustained Read | 30MB/S | 33MB/S | 73MB/s | 72MB/S | 73MB/S | 154MB/S | 155MB/S | 158MB/S | |
| Sustained Write | 8MB/S | 7MB/S | 14MB/s | 16MB/S | 15MB/S | 32MB/S | 35MB/S | 107MB/S | |
| 4KB Sequential Read IOPS | 6K | ||||||||
| 4KB Sequential Write IOPS | 6K | ||||||||
| Average Access time | 0.2ms | ||||||||
| Storage Media | NAND Flash | MLC | |||||||
| Power Consumption | input Voltage | 5V± 5% | |||||||
| Idle | 0.5W | ||||||||
| Active | 2.0W | ||||||||
| Reliability& Endurance | Write endurance | 8years @100GBytes write and erase per day at 32GB | |||||||
| Read endurance | unlimited | ||||||||
| Wear-Leveling Algorithm | Dynamic and static wear-leveling | ||||||||
| Data Retention | 10years at 25ºC | ||||||||
| MTBF | 1,000,000hours | ||||||||
| ECC | Supports BCH ECC 8bits or 15bits in 512 bytes | ||||||||
| Bad Block Management | Auto Bad Block Management in system | ||||||||
| Environment | Operating Temperature | 0~75ºC | |||||||
| Non-operating Temperature | -40~85ºC | ||||||||
| Shock | 2,000G(@0.3ms half sine wave) | ||||||||
| Vibration | 20G(40-2000HZ) | ||||||||
| Humidity | 5-95% | ||||||||
| Warranty | 2years | ||||||||
| Available unit | Available,NO EOL | ||||||||
| Testing Platform | CPU:Intel® Core™ i3 Duo CPU 540 @ 3.07GHz Chipset:Intel® H55 Express Chipset Memory:Kingston KVR800D2N5/2G OS:Microsoft Windows 7 Professional 64-bit AHCI Driver:Intel® Rapid Storage Technology – Intel® ICH10R SATA AHCI Controlle v9.6 BIOS Settings: AHCI Mode |
||||||||
| Testing Software | ATTO Disk Benchmark,CrystalDiskMark v3.0 ,HD Tach RW 3.0.1.0,HD Tune PRO 3.50 | ||||||||
| Physical Dimensions & Weight |
Height(mm) | 10.72+/_0.1 | |||||||
| Width(mm) | 29.87.+/_0.1 | ||||||||
| Length(mm) | 44.07+/_0.1 | ||||||||
| Weight(g) | TBD | ||||||||
| The read and write speed is limited to this test platform. | |||||||||
