Home > Manufacturing & Processing Machinery > Woodworking Machinery > Other Woodworking Machinery > China Supplier Knife Grinder Sharpener Machine Used for Sharpening the Wood Chipper Knife With CE 008613253417552

China Supplier Knife Grinder Sharpener Machine Used for Sharpening the Wood Chipper Knife With CE 008613253417552

China Supplier Knife Grinder Sharpener Machine Used for Sharpening the Wood Chipper Knife With CE 008613253417552 photo-1
China Supplier Knife Grinder Sharpener Machine Used for Sharpening the Wood Chipper Knife With CE 008613253417552 photo-2
China Supplier Knife Grinder Sharpener Machine Used for Sharpening the Wood Chipper Knife With CE 008613253417552 photo-3
China Supplier Knife Grinder Sharpener Machine Used for Sharpening the Wood Chipper Knife With CE 008613253417552 photo-4
China Supplier Knife Grinder Sharpener Machine Used for Sharpening the Wood Chipper Knife With CE 008613253417552 photo-5
China Supplier Knife Grinder Sharpener Machine Used for Sharpening the Wood Chipper Knife With CE 008613253417552 photo-6
US$ 500 - 1,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
BEDO
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao or sanghai port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name BEDO
Model Number BD-800
After-sales Service Provided Engineers available to service machinery overseas

China supplier knife grinder sharpener machine  used for sharpening the wood chipper knife with CE 008613253417552



Product Description





China supplier knife grinder sharpener machine used for sharpening the wood chipper knife with CE 008613253417552China supplier knife grinder sharpener machine used for sharpening the wood chipper knife with CE 008613253417552

 China supplier knife grinder sharpener machine used for sharpening the wood chipper knife with CE 008613253417552

1. Introductions of the  knife grinder sharpener machine :

1,when sharpening,need to press the blade tightly,then start the switch.

2,When switch start,It is forbidden to reverse, Must be started in the direction shown by the arrow,and adjust direction switch timely.

3,When switch start,first  to Start the grinding wheel switch,then start travel switch

4,When sharpening,the machine is advisable to put five times per minute or so, can be continuous use, if more than 5 times, should be pay attention to frequency conversion motor to heat up, in case burn out.

5,Grinding wheel screw can debug by itself.

6,If the machine with automatic lifting plate, debugging board Angle first, and then put the screws, set, adjustable trip to meet again, at run time, the lifting plate tooth run a stroke can touch on the lifting screw gear of a tooth.

7,The travel swith can adjust by itself from 300-800cm.

2.  Main parameters of the   knife grinder sharpener machine :


Knife grinder   BD-K800

Maximum travel

800MM

Grinding wheel hoisting height

110mm

Grinding wheel speed

2800RMP

Main motor power

1.5kw

Grinding wheel size

125*65mm

weight
 148kg

Angle grinder

28/35/90 degree

Package

wooden case

Size

1380*800*1100mm

Moving motor Power

0.75kw

Water pump power

0.04kw

 China supplier knife grinder sharpener machine used for sharpening the wood chipper knife with CE 008613253417552China supplier knife grinder sharpener machine used for sharpening the wood chipper knife with CE 008613253417552China supplier knife grinder sharpener machine used for sharpening the wood chipper knife with CE 008613253417552China supplier knife grinder sharpener machine used for sharpening the wood chipper knife with CE 008613253417552





China supplier knife grinder sharpener machine used for sharpening the wood chipper knife with CE 008613253417552

China supplier knife grinder sharpener machine used for sharpening the wood chipper knife with CE 008613253417552China supplier knife grinder sharpener machine used for sharpening the wood chipper knife with CE 008613253417552China supplier knife grinder sharpener machine used for sharpening the wood chipper knife with CE 008613253417552

China supplier knife grinder sharpener machine used for sharpening the wood chipper knife with CE 008613253417552China supplier knife grinder sharpener machine used for sharpening the wood chipper knife with CE 008613253417552
