China 7 - 9 ton Capacity metal wood chipper machine, Wood Drum Chipper for fiber - board plant 008613253417552
I. Introduction of the metal wood chipper machine :
The Drum wood chipper is a special device of producing wood chips. It is widely used in stock workshop section of industrial manufacture, for example, the flakeboard,fibre board, building board, straw power plant.
Its raw materials are mainly small diametre, leaving thing of wood cutting(branchs ,wattle) and process leaving thing of the wood raw materials (board skin, board bar, log core,waste veneer) and so on. It also can cut the non-wood materias, like sugar cane, bulrush,gross bamboo and so on.
2. Raw material of the metal wood chipper machine :
The raw material is small diameter wood, timber harvesting, processing residues (such as branches, twigs, planks, logs cores, waste veneer, etc.), it can also be used for cutting non-wood materials (such as sugar cane, reed, bamboo, etc
3. Technical Parameters of the metal wood chipper machine :
Model |
BD-BX215 |
BD-BX216 |
BD-BX218 |
BD-BX2113 |
Inlet size(H*W) (mm) |
160*400 |
230*500 |
300*680 |
450*700 |
Blades number (pcs) |
2 |
2 |
2 |
2 |
Knife roller speed (turn) |
592 |
590 |
650 |
500 |
Max. Diameter (mm) |
160 |
230 |
300 |
450 |
Woodchips size (mm) |
30 |
30 |
30 |
38 |
Capacity (T) |
3-4 |
7-8 |
12-15 |
15-30 |
Main motor power (kw) |
45 |
55 |
110 |
200-250 |
|
Feed roller motor power (kw) |
2.2-3 |
3-4 |
4-5 |
7.5*2 |
Oil pump motor power (kw) |
1.5*1 |
1.5*1 |
1.5*1 |
3*1 |
Weight (kg) |
2990 |
5030 |
7000 |
11840 |
Outline Dimension (mm) |
1470×1550×970 |
1800×1900×1210 |
2200×2150×1500 |
3670*2517*2050 |
Conveyor motor power (kw) |
3 |
3 |
3 |
3 |
4. The photos of the structure of metal wood chipper machine :
5. The phtos of the metal wood chipper machine in our plant :
Note :
The final chips could be 6-8mm,8-10mm,10-20mm,20-30mm etc. it will depend on customer's request.
the machine can be drive by electric motors or diesel engine.
it can be designed moveable.
If you are interested in our products, pls feel free to contact me.
Bella is always at your services
My Contact way : Skype: bedomachinery01
cell : 008613253417552
Your Success Is Our Business!
