SYST series tablet press is our newest generation R&D result into the market,also it is one of the most advanced tablet forming machine.Compared with the common tablet press machine,its main advantages lies in:
1.Fully CNC control design
2.Fully intelligent operation design
3.Fully-automatic material filling design
4.Isolated hydraulic station design
5.Reasonable structure design
6.Demoulding protection
7.Uniform density
8.Different layer different color
9.Mutiple production capacity
10.Safety protection
Machine Highlights
- The whole machine is made of stainless steel,which can prevent from polutions,conform with GMP standard.And the Work platform is clean enough so that we get the light demolition,internal cleaning convenience purposes.
- Equipped with a transparent viewing window to enable operators can see the whole system working condition.
- Adopted PLC programming controller for the wholly system, realized bi-directional repression.Imported hydraulic components are used on this machine, all the key positions can be dually operated by mechanical and electrical ways.All of the operations can be adjusted through the PLC to the best state.Therefore,the machine is quite easy to be operated, can work stably,safly and accurately.
- The hydraulic components are equipped inside of the machine and independent to prevent the damage from outside,pollution-free ,easy to release the heat and the control panel can be design to demonstrate in different foreign languages.
Model |
SYST-45 |
SYST-100 |
SYST-200 |
Working pressure |
45T |
100T |
200T |
Ascending stroke |
150mm |
200mm |
200mm |
Feeding height |
150mm |
180mm |
200mm |
Diameter of the below mould |
300mm |
300mm |
300mm |
Max briquette diameter |
200mm |
200mm |
200mm |
output |
3-4 cycle per minute |
3-4 cycle per minute |
3-4 cycle per minute |
Motor power |
7.5kw |
11kw |
15kw |
Machine size |
1.8*1.5*2.5M |
1.8*1.6*2.6M |
2.3*1.6*3.2M |
Machine Weight |
2300kg |
3500kg | 4500kg |
Our Standard Payment Practice is:
30% T/T pre-paid upon confirmation PO and 70% T/T paid before shipment FOB Shanghai
Packed in Export standard wooden case
Delivery time:
Under 200t(including 200t):within 40 working days
Above 200t:within 60 working days
All machines would be strictly checked and tested before leaving factory
Accessories
Our company has been engaged in the research,development and manufacture of non-standard tablet press machine. Our tablet press machine have broad scope of application. At the same time, offer molding manufacturing service. We have accumulated a lot of material tablet compressing experience. Besides offering tablet press machine and mould, we also can give some technical support on tablet press machine & mould for customers.
We have exported toUK, Algeria,Brazil,Egypt, India, Thailand, Saudi Arabia, Russia, Spain, Pakistan, Turkey, Lebanon,USA, South Korea, Sudan, Argentina and so on.
Pre-sale Service
We provide professional consultation about each type of machine,and offer free material testing service to help customers purchase suitable machine.Customers are also welcomed to visit and evaluate our factory.
After-sale Service
After customers received tablet press machine, we will arrange our technician go to your factory to help you instal and debug the machine,also provide technical training for your workers.
The warranty for this machine will be one year, we will provide vulnerable parts and door-to-door service by free within one year.
Changzhou Jingfeng Packing Technology Co., Ltd. was established in 1986, two decades has been engaged in a variety of powder forming tablet machine R & D and manufacture of products with good quality and excellent after-sales service won the pre-sale home and abroad customers. The company has a strong technical force in the design and development team, engaged in equipment manufacturing, as well as supporting mold processing. Company's existing products to a single impulse-type tablet machine, hydraulic pressure tablets, pressing machine-based. Equipment, convenient operation, high stability, automated production machines can be realized more than one person, one-mode multi-pressure mode of operation, greatly improving the efficiency of production. Ceramic powder is widely used in dry-pressed, powder metallurgy, magnetic materials, chemical powder molding, electronics, pharmaceuticals and other industries, the real meaning to meet the different needs of customers. The company adhere to a sincere attitude, customer-oriented, quality and service first, enthusiastically looking forward to new and old customers at home and abroad to guide co-operation.
Exhibition Images
Contact Information
FAQ
- Delivery date
We will arrange the production and shipment as soon as we received the deposit,and update the information with customers timely.Generally,the delivery time will not exceed 60 working days.
- Terms of payment
Normally,when th order value is below US$10,000,we can accept the payment by T/T or Western Union or Cash.For T/T,the customer can choose 100% in advance or 30% in advance,and pay the 70% balance before shipment.
- After -sale service
For most of the machines,the warranty will be one year since the date of shipment,we supply the on-line service for all the customers,and also supply the spare parts all the time with cost price,for some complicate machine or part,we can send our technicians overseas to help debug too.
- How do you guarantee I can receive ordered goods after payment?
We are a legally established company supervised by the government,and is registered in customs of China and China Chamber of International Commerce.Besides,we are the member of Alibaba and has been checked by the third part as the real and legal company,So,please rest assured.What is more,honesty and trustworthiness is our basic principle and company motor.
- How to make an order?
Step 1.Please tell us your material characteristic and the diameter&height you require
Step 2.Then we will make a solution for you to confirm the order details
Step 3.You can send us some material to test,or you can visit our factory
Step 4.Finally,make a deal and we will deliver the goods with the stipulated time
