Easy access vertical platform lift elevators for disabled
Easy installation and easy operation for people lifting. Height can be customized.
Vertical platform lift for disabled adopts new material aluminium Alloy, which made the lift to be light
weight, more durable and easy installation. It can easily lift the person and wheelchair with the capacity 250kg or more if you need.
Vertical platform lift consists of a platform with guard plate, drive tower, automatic or stationary
ramp and operating controls. It is assembled well before shipment, so after recepit, very easy installation.
Disabled lift elevators Parts
1. Column button: It is fixed on the ground and upper floor for the user easy operation with “UP”, “Down” and E-Stop button.
2. Drive tower: The platform will go up by climing the drive tower, it contains pump station, hydraulic cylinder.
3. Control Panel: Apart from “UP”, “Down” and E-Stop button on it, there is still with keys, when no use,
we can lock the lift.
4. Handrail: When the users enter into the platform, they can hold on it for safety when lifting up and down.
5. Automatic ramp: When the platform off the ground, it will fold up automatically to ensure the users safety.
Disabled lift elevators offers wheelchair users the opportunity to move freely within a multi-floored building while taking the wheelchair with them so they are fully independent between floors. The lift can both be indoor or outdoor installation.
Model |
Lifting height |
Load capacity |
Platform size |
Self weight |
Manual Door |
VPL-1 |
1000mm |
250kg |
1430*900mm |
350kg |
Yes |
VPL-2 |
2000mm |
250kg |
1430*900mm |
550kg |
Yes |
VPL-3 |
3000mm |
250kg |
1430*900mm |
780kg |
Yes |
VPL-4 |
4000mm |
250kg |
1430*900mm |
880kg |
Yes |
VPL-5 |
5000mm |
250kg |
1430*900mm |
1000kg |
Yes |
VPL-6 |
6000mm |
250kg |
1430*900mm |
1100kg |
Yes |
All the load capacity, lifting height, platform size can be customized according to your request!
Taking this discount coupon can help you save USD100 for one lift, hurry to leave message!!!
The vertical platform lift will be packed into steel framed plywood cases for safety shipment.
Below are some related products along with the vertical platform lift. Pls click and review more info in needed.
Scissor dock lift Trailer boom lift Hydraulic goods lift
SHANDONG GEM MACHINERY CO., LTD factory was founded in the year 1999 and started the production
of scissor lifts, cargo lifts, dock ramp and so on. After years development, GEMWAY has manufactured many new lifts such as towable boom lift, wheelchair lift, electric scissor lift and so on. All the products are
manufactured under the standard of CE certification.
Each month, GEM machinery is visited by many customers from different countries. They coming for test
our lifts, plants, designs and place the order in the office after negotiation. Welcome you to come and test
GEMWAY lifts in person.
