Home > Products > Wheelchair lift > Aluminum material hydraulic wheelchair platform lift elevator
Aluminum material hydraulic wheelchair platform lift elevator
- 20 Unit / Units per Month
- Qingdao Port China for Wheelchair platform lift
- T/T Credit Card PayPal
- China easy operated scissor lift platform, truck mounted platform scissor lift
- China low cost hydraulic elevating platform, truck mounted platform scissor lift
- 2015 hot sale double ladder stop type hydraulic scaffolding lift
- Big discount offered 8m lift self propelled hydraulic outdoor aerial work platform scissor lift
- China factory direct sale self propelled scissor lift table / hydraulic scissor lift
- China good working performance hydraulic scissor lift table, electric mini scissor lift
Product Details
Place of Origin: | Shandong, China | Brand Name: | Gemway | Model Number: | VPL-4 |
Lift Mechanism: | Lift Chain | Lift Drive / Actuation: | Hydraulic | Power: | 0.75kw, AC power |
Rated Loading Capacity: | 250kg | Min. Lifting Height: | 200mm | Max. Lifting Height: | 4000mm |
Table Size: | 1430*900mm | Overall Dimensions: | 5100*1430*1000mm | Weight: | 880kg |
Certification: | CE/ISO9001 | Warranty: | 12 Months after receipt | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Aluminum material hydraulic wheelchair platform lift elevator
Easy installation and easy operation for people lifting. Height can be customized.
Wheelchair platform lift adopts new material-aluminium Alloy, which made the lift to be light weight,
more durable and easy installation. It can easily lift the person and wheelchair with the capacity 250kg
or more you need.
Wheelchair elevator lift for home consists of a platform with guard plate, drive tower, automatic
or stationary ramp and operating controls. It is assembled well before shipment, so after recepit, very easy installation.
wheelchair platform lift parts
1. Easy installation: the lift can be installed directly onto ground.
2. Safety sensor: The platform will go stop immedieatly meets something under it.
3. Remote control: Besides control column and control panel, remote control also available.
4. Manual dowm: Once the electric power is off, people can let the lift down by manual down device.
Wheelchair lift will be packed into steel framed plywood cases for safety shipment.
Hydraulic wheelchair lifts offers wheelchair users the opportunity to move freely within a multi-floored building while taking the wheelchair with them so they are fully independent between floors.
Model | Lifting height | Load capacity | Platform size | Self weight | Manual Door |
VPL-1 | 1000mm | 250kg | 1430*900mm | 350kg | Yes |
VPL-2 | 2000mm | 250kg | 1430*900mm | 550kg | Yes |
VPL-3 | 3000mm | 250kg | 1430*900mm | 780kg | Yes |
VPL-4 | 4000mm | 250kg | 1430*900mm | 880kg | Yes |
VPL-5 | 5000mm | 250kg | 1430*900mm | 1000kg | Yes |
VPL-6 | 6000MM | 250kg | 1430*900mm | 1100kg | Yes |
Lifting height can be customized.
Taking this discount coupon can help you save USD100 for one lift, hurry to leave message!!!
Below are some related products along with the wheelchair lift. Pls click and review more info in needed.
Scissor lift table Vertical man lift Self propelled man lift
SHANDONG GEM MACHINERY CO., LTD factory was founded in the year 1999 and started the production
of scissor lifts, cargo lifts, dock ramp and so on. After years development, GEMWAY has manufactured many
new lifts such as towable boom lift, wheelchair lift, electric scissor lift and so on. All the products are
manufactured under the standard of CE certification.
Each month, GEM machinery is visited by many customers from different countries. They coming for test our
lifts, plants, designs and place the order in the office after negotiation. Welcome you to come and test
GEMWAY lifts in person.
