14m Portable Hydraulic Scissor Lift Table Machine
- Qingdao
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | GEMWAY | |
| Model Number | MSL-14 | Lift Mechanism | Scissor Lift | |
| Lift Drive / Actuation | Electric Motor | Power | 3kw, AC power | |
| Rated Loading Capacity | 500kg | Min. Lifting Height | 1.81m | |
| Max. Lifting Height | 14m | Table Size | 2815*1530mm | |
| Overall Dimensions | 3045*1730*1810mm | Weight | 2400kg | |
| Certification | CE ISO9001 | Warranty | 12 Months after receipt | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
14m portable hydraulic scissor lift table machine
Hydraulic scissor lift table is a scissor structure man lift for aerial work which can be towed by
man power.The mechanical structure make the platform stability, wide operating and high loading capacity. Normal portable hydraulic lift lifting power is AC power, DC and Diesel power are also available for option.
Hydraulic lift machine is easily operated by the control box both on the platform and ground. The supporting legs can guarantee the stability of the lift. More safety for works working on the platform with the guardrail. Besides the AC power, you also can add battery or diesel power for assist walking.
Hydraulic lift machine can be used in the factory, warehouse, public places , stations and so on. It provides you a good choice for aerial working.
Model | Load | Lifting height | Platform size | Overall Dimension
|
MSL4 | 500kg | 4m | 2100*820mm | 2200*950*1100mm |
MSL6 | 500kg | 6m | 2100*820mm | 2200*950*1200mm |
MSL7 | 500kg | 7m | 2100*820mm | 2200*950*1280mmm |
MSL8 | 500kg | 8m | 2100*900mm | 2200*950*1200mm |
MSL9 | 500kg | 9m | 2100*900mm | 2200*1060*1500mm |
MSL10 | 500kg | 10m | 2100*1200mm | 2200*1060*1380mm |
MSL11 | 500kg | 11m | 2100*1200mm | 2200*1400*1700mm |
MSL12 | 500kg | 12m | 2550*1500mm | 2200*1400*1550mm |
MSL14 | 500kg | 14m | 2815*1530mm | 3045*1730*1810mm |
MSL16 | 500kg | 16m | 3070*1600mm | 3250*1800*1920mm |
MSL18 | 500kg | 18m | 3070*1600mm | 3250*1800*2080mm |
SHANDONG GEM MACHINERY CO., LTD factory was founded in the year 1999 and started the production of scissor lifts, cargo lifts, dock ramp and so on. After years development, GEMWAY has manufactured many new lifts such as towable boom lift, wheelchair lift, electric scissor lift and so on. All the products are manufactured under the standard of CE certification.
Each month, GEM machinery is visited by many customers from different countries. They coming for test our lifts, plants, designs and place the order in the office after negotiation. Welcome you to come and test GEMWAY lifts in person.
SHANDONG GEM MACHINERY CO., LTD
TEL: +86 531 55572657
TEL: +86 531 55572658
EMAIL: sales(at)
