4m-20m Outdoor manual mobile hydraulic lift table with scissor structure
Mobie scissor lift can be moved easily, suitable for indoor and outdoor works, plentiful stocks are waiting for your order.
Mobile hydraulic lift is a scissor structure man lift for aerial work which can be towed by man power.
The mechanical structure make the platform stability, wide operating and high loading capacity.
Mobile scissor lift table is easily operated by the control box both on the platform and ground. The supporting legs can guarantee the stability of the lift. More safety for works working on the platform with the guardrail. Besides the AC power, you also can add battery or diesel power for assist walking.
1. Trailing bar: Easy for manual power to trail this lift to move.
2. Power unit: Durable power units with pump station and electric parts.
3. Supporting legs: Strong supporting with 4 pcs legs.
4. Control panel: Easy control for both platform and ground.
5. Attaching Plug: Wires can be connected directly by this plug.
Manual scissor lift platform can be used in the factory, warehouse, public places , stations and so on. It provides you a good choice for aerial working.
Model |
Load |
Lifting height |
Platform size |
Overall Dimension
|
MSL4 |
500kg |
4m |
2100*820mm |
2200*950*1100mm |
MSL6 |
500kg |
6m |
2100*820mm |
2200*950*1200mm |
MSL7 |
500kg |
7m |
2100*820mm |
2200*950*1280mmm |
MSL8 |
500kg |
8m |
2100*900mm |
2200*950*1200mm |
MSL9 |
500kg |
9m |
2100*900mm |
2200*1060*1500mm |
MSL10 |
500kg |
10m |
2100*1200mm |
2200*1060*1380mm |
MSL11 |
500kg |
11m |
2100*1200mm |
2200*1400*1700mm |
MSL12 |
500kg |
12m |
2550*1500mm |
2200*1400*1550mm |
MSL14 |
500kg |
14m |
2815*1530mm |
3045*1730*1810mm |
MSL16 |
500kg |
16m |
3070*1600mm |
3250*1800*1920mm |
MSL18 |
500kg |
18m |
3070*1600mm |
3250*1800*2080mm |
We do good package before shipment, which can ensure our lift to be protected well when delivery to our customers.
Marketing promotion will last until Sept. 31st, 2016. Pls take this for 100 dollars discount.
Below are some related products along with the portable scissor lift. Pls click and review more info in needed.
Vertical mast man lift Self propelled scissor lift 200kg man lift
SHANDONG GEM MACHINERY CO., LTD factory was founded in the year 1999 and started the production of scissor lifts, cargo lifts, dock ramp and so on. After years development, GEMWAY has manufactured many
new lifts such as towable boom lift, wheelchair lift, electric scissor lift and so on. All the products are
manufactured under the standard of CE certification.
Each month, GEM machinery is visited by many customers from different countries. They coming for test our
lifts, plants, designs and place the order in the office after negotiation. Welcome you to come and test
GEMWAY lifts in person.
