Help CenterModern High-grade Warehouse Loading Stationary Dock Leveler or Fixed Dock Ramp
Related Products
-
Heavy Duty Stationary Dock Ramp for Forklift Loading and Unloading RampsUS$ 2,960 - 5,820MOQ: 1 Set -
Best Price High Standard Hydraulic Stationary Dock Leveler From China SupplierUS$ 2,960 - 5,820MOQ: 1 Set
-
Durable Service Better Price Stationary Mini Dock Leveler With Trade AssuranceUS$ 2,960 - 5,820MOQ: 1 Set
-
10ton Hydraulic Electric Dock LevelerUS$ 2,960 - 5,820MOQ: 1 Set
-
8ton Hydraulic Loading Dock LevelersUS$ 2,960 - 5,820MOQ: 1 Set
Mobile dock yard ramp is a stationed hydraulic equipment used for truck loading and unloading outside the warehouses or workshops. Its ramp can be adjusted higher or lower the level, so then the forklifts can go in and out the truck or container to load the goods.
Specification
Hydraulic loading dock leveler mainly composed of main frame and hydraulic system. To make this leveler more stable and safe, we designed some small featured parts maintain support bar, legs, safety boards are showing in below photo.
Parts Introduction
|
1. Anti-ski platform: To protect materials from falling. 2. Safety trip bar: It located directly underneath the platform to prevent injury from use. 3. Hydraulic cylinder: High precision wear-resisting hydro-cylinder with locking device for fall protection. 4. Scissor structure: High-strength Manganese steel. 5. Control box: The "UP", "DOWN" and "EMERGENCY STOP" buttons are extremely easy to use on each floor. 6. Pump station: Provide a certain pressure and flow of hydraulic oil. 7. Lifting hook: It’s easier for crane to put it into the pit.
|
Dock leveler for truck is installed in the pit outside the warehouses, workshops, wharf, logistics base, postal transportation, logistics distribution etc. It brings high work efficiency to daily cargo loading from or to truck containers.
Models List
Model |
Load |
Height range |
Platform size (m) |
DL-6 |
6T |
+0.40/-0.3m |
2*2 |
DL-8 |
8T |
+0.40/-0.3m |
2*2 |
DL-10 |
10T |
+0.40/-0.3m |
2*2 |
DL-12 |
12T |
+0.40/-0.3m |
2*2 |
DL-15 |
15T |
+0.40/-0.3m |
2*2 |
DL-N |
Load capacity, adjusting range, platform size, color all can be customized according to requests. |
||
|
SHANDONG GEM MACHINERY CO., LTD factory was founded in the year 1999 and started the production of scissor lifts, cargo lifts, dock ramp and so on. After years development, GEMWAY has manufactured many new lifts such as towable boom lift, wheelchair lift, electric scissor lift and so on. All the products are manufactured under the standard of CE certification. |
|
Each month, GEM machinery is visited by many customers from different countries. They coming for test our lifts, plants, designs and place the order in the office after negotiation. Welcome you to come and test GEMWAY lifts in person. |
