Help CenterOutdoor Swimming Pool Tents With Aluminum Structural
Related Products
-
Large Temporary Tennis Court Tent for EventsUS$ 20 - 80MOQ: 1 Set -
Commercial Swim Pool Tents PvcUS$ 20 - 80MOQ: 1 Set
-
Large Swimming Pool Cover Tent for SaleUS$ 20 - 80MOQ: 1 Set
-
High Quality Outdoor Swimming Pool TentUS$ 20 - 80MOQ: 1 Set
-
High Quality Structural Out Swimming Pool TentUS$ 20 - 80MOQ: 1 Set
Specifications
Outdoor swimming pool tentsMaterial:Aluminum frame PVC fabric
Shape:Rectangular shape
Width:3-40m
Length:Unlimited
1. Specifications
1) Size: from 3 meters to 40meters
2) Eave height: standard from 2.5m, 3m, 4m to 5m upon span width (or special height per requested)
3) Length: Unlimited, extended by 3m or 5m each bay
2. Frame part
1) The main parts are made of aluminum alloy and the spare parts are made of steel.
2) All aluminum components are technically anodized and all steel parts are well hot-dip galvanized.
3. Cover Part
1) The roof and sidewall fabric cover are made of double coated PVC.
2) The fabric is waterproof and UV resistant.
3) The fabric is flame retardant to DIN4102, M2 and Grade B1.
4) The weight of fabric is from 650g/sqm to 850g/sqm.
Product parameter:
| Item | MST L series | |||
| Span/width | 3m-40m | |||
| Length | unlimited, standard 6m,9m,12m,+3m …... or 10m, 15m, 20m, +5m …... | |||
| Side height | 2.5m, 3m, 4m, 5m | |||
| Bay distance | 3m/4m/5m | |||
| How to choose the tent size | We suggest 1-1.5sqm/person |
|||
| Frame material | High reinforce aluminum alloy, anti-rust surface | |||
| Fabric material | 650-850g double coated pvc fabric, flame retardant, UV resistance, waterproof, comply to DIN4102, B1, M2(European standard) | |||
| wind load | 80km/h ( 0.3km/sqm ). | |||
| space utilization | 100% | |||
| Installation | installation video or manual can be provided | |||
| Application |
wedding, party, event, ceremony, exhibition, warehouse, storage......
|
|||
Detailed specification chart:
Specification |
Span width (m) |
Bay spacing (m) |
Eave height (m) |
Ridge height (m) |
Main frame profile (mm) |
MST-3 |
3 |
3 |
2.5 |
3 |
48×84×3 |
MST-6 |
6 |
3 |
2.5 |
3.5 |
48×84×3 |
MST-8 |
8 |
3 |
2.5 |
3.9 |
48×84×3 |
MST-10 |
10 |
3 |
2.5 |
4.3 |
48×84×3 |
MST-15 |
15 |
5 |
4 |
6.43 |
108×150×3 |
MST-18 |
18 |
5 |
4 |
6.9 |
112×203×4.5 |
MST-20 |
20 |
5 |
4 |
7.2 |
112×203×4.5 |
MST-25 |
25 |
5 |
4 |
8.0 |
112×203×4.5 |
MST-30 |
30 |
5 |
4 |
8.8 |
112×259×5.5 |
MST-40 |
40 |
5 |
4 |
9.6 |
115×307×6.0 |
4. Optional Accessories
1) Sidewall with transparent PVC window
2) Rain gutters
3) Glass door and glass wall
4) Curtain lining
5) Flooring system
5. Advantages
1) Easy to disassemble and assemble.
2) Small storage volume.
3) Space is 100% available.
