New product promotion High temperature smco block magnet

Name: New product promotion High temperature smco block magnet
Brand: HONESUN
Availability: InStock

FOB Price

USD $1 - $100 / Piece

1 Piece(Min.Order)

Supply Ability 50 Ton / Tons per Month
Port SHANGHAI/NINGBO/HANGZHOU
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	HONESUN
Model Number	HS-SC001	Type	Permanent
Composite	Rare Earth Magnet	Shape	Coil
Application	Industrial Magnet

Product Description

Description:	SmCo Magnet
Material:	Samarium cobalt magnet
Product Name:	SmCo Magnets,Samarium cobalt magnet,Sintered Rare Earth Magnets,Permanent Magnets

Working Temperature:	Grade	Temperature
	SmCo5(YX16,YX18,YX20,YX22,YX24)	250ºC
	Sm2Co17(YXG24,YXG26,YXG28,YXG30,YXG32)	250~350ºC
Magnet Shape:	Disc,Cylinder,Block,Ring,Countersunk,Segment,Trapezoid and Irregular shapes and more.Customized shapes are available


Magnet Coating:	Ni,Zn,Au,Ag,Epoxy,Passivated,etc
Features:	Samarium cobalt magnets (SmCo) are composed of samarium, cobalt and iron. These rare earth magnets are extremely strong for their small size, metallic in appearance and found in simple shapes such as rings, blocks and discs.. The highest commercially available energy products of Sm2Co 17 are in the 30MGOe range



	High resistance to demagnetization
	High Energy Product
	Good temperature stability
	High resistance of corrosion and oxidation
	Expensive material (cobalt is market price sensitive)
Applications:	Fireplace door, Computer disc drives, Sensors,Radar,Traveling wave tubes, Satellite systems,motors,filter automobiles,magnetics holders,loudspeakers,wind generators, medical equipments, etc.

Material Science	Grade	Br		Hcb		Hcj		(BH)max
1:5 SmCo5(SmPr)Co5		T	KGs	KA/m	KOe	KA/m	KOe	KJ/m3	MGOe
	YX-16	0.81-0.85	8.1-8.5	620-660	7.8-8.3	1194-1830	15-23	110-127	14-16
	YX-18	0.85-0.90	8.5-9.0	660-700	8.3-8.8	1194-1830	15-23	127-143	16-18
	YX-20	0.90-0.94	9.0-9.4	676-725	8.5-9.1	1194-1830	15-23	150-167	19-21
	YX-22	0.92-0.96	9.2-9.6	710-748	8.9-9.4	1194-1830	15-23	160-175	20-22
	YX-24	0.96-1.00	9.6-10.0	730-770	9.2-9.7	1194-1830	15-23	175-190	22-24
1:5 SmCo5	YX-16s	0.79-0.84	7.9-8.4	620-660	7.8-8.3	≥1830	≥23	118-135	15-17
	YX-18s	0.84-0.89	8.4-8.9	660-700	8.3-8.8	≥1830	≥23	135-151	17-19
	YX-20s	0.89-0.93	8.9-9.3	684-732	8.6-9.2	≥1830	≥23	150-167	19-21
	YX-22s	0.92-0.96	9.2-9.6	710-756	8.9-9.5	≥1830	≥23	167-183	21-23
	YX-24s	0.96-1.00	9.6-10.0	740-788	9.3-9.9	≥1830		183-199	23-25
low temperature coefficient 1:5 (SmGd)Co5	LTc(YX-10)	0.62-0.66	6.2-6.6	485-517	6.1-6.5	≥1830	≥23	75-88	9.5-11
2:17 Sm2(CoFeCuZr)17	YXG-24H	0.95-1.02	9.5-10.2	692-764	8.7-9.6	≥1990	≥25	175-191	22-24
	YXG-26H	1.02-1.05	10.2-10.5	748-796	9.4-10.0	≥1990	≥25	191-207	24-26
	YXG-28H	1.03-1.08	10.3-10.8	756-812	9.5-10.2	≥1990	≥25	207-220	26-28
	YXG-30H	1.08-1.10	10.8-11.0	788-835	9.9-10.5	≥1990	≥25	220-240	28-30
	YXG-32H	1.10-1.13	11.0-11.3	812-860	10.2-10.8	≥1990	≥25	230-255	29-32
	YXG-22	0.93-0.97	9.3-9.7	676-740	8.5-9.3	≥1433	≥18	160-183	20-23
	YXG-24	0.95-1.02	9.5-10.2	692-764	8.7-9.6	≥1433	≥18	175-191	22-24
	YXG-26	1.02-1.05	10.2-10.5	748-796	9.4-10.0	≥1433	≥18	191-207	24-26
	YXG-28	1.03-1.08	10.3-10.8	756-812	9.5-10.2	≥1433	≥18	207-220	26-28
	YXG-30	1.08-1.10	10.8-11.0	788-835	9.9-10.5	≥1433	≥18	220-240	28-30
	YXG-32	1.10-1.13	11.0-11.3	812-860	10.2-10.8	≥1433	≥18	230-255	29-32
low temperature coefficient 2:17 (SmEr)2(CoTm)17	LTC(YXG-22)	0.94-0.98	9.4-9.8	668-716	8.4-9.0	≥1433	≥18	167-183	21-23
