2.8 inch TFT 240x320 COG lcd display
- 100000 Piece / Pieces per Month
- Shenzhen
- T/T D/P D/A Credit Card
- negative segment character running machine lcd display,practical STN,blue backlight, fitness equipment
- digital fire alarm installation module display, HTN segment display with blue led lcd panel
- negative autoreclose circuit-breaker lcd display, segment module with blue led
- charger negative character lcd display,white led ,battery segment small flexible display
- character small charger lcd display ,custom battery display ,white led
- segment positive temperature time clock lcd display,blue TN white backlight
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Crystal-Run | Model Number: | JRTFT-21146 |
Type: | COG |
Product Description
Specifications
2.8 inch TFT 240x320 COG lcd display:1.reasonable price
2.best quality
3.good service
4.fast delivery time
2.8 inch TFT 240x320 COG lcd display:
DISPLAY CHARACTERISTICS
ITEM | DESCRIPTION |
LCD Display Mode | TFT,negative,Transmissive |
View Angle | 6:00 |
Driving Method | 1/64 duty, 1/9 bias |
Backlight | white |
MECHANICAL DATA
ITEM | DESCRIPTION |
Outline(mm) | 50.00x69.20x2.3 |
Viewing Area(mm) | 45.30x59.60 |
Active Area(mm) | 43.20x57.60 |
Dot Pitch(mm) | 0.180x0.180 |
Dot Size(mm) | 0.083x0.083 |
ABSOLUTE MAXIMUM
ITEM | DESCRIPTION |
Operation Voltage(v) | VLCD:3.0V |
Operation temperature | -20-70°C |
Storage Temperature | -30-80°C |
Package and delivery details:
Packaging Detail: | our company standard |
Delivery Detail | 25 to 30 days after the order released |
operations
1 It is essencial to drive the lcd with the specified voltage limits ,since a higher driving voltage than allowed causes a shorter lcd liftime.
2 The response time of the lcd liquid is considerably longer at low temperature than in the normal operting temperature range .On the other hand ,the lcd will show a dark blue colour at high temperatures .Those phenomena do not indicate a malfunction or defect of the lcd. Back at normal temperature ,the lcd will return to its original behavior .
Competitive advantages :
1 reasonable price
2 ROHS compliant
3 sample available as request
4 long life span : 10 years
Our company has build up more than 6 years .With thesed years' effort ,we have made much progress in this field, including technology and management. More information:
