Home > Products > vacuum forming products > Outdoor customized shape vacuum formed plastic light box

Outdoor customized shape vacuum formed plastic light box

FOB Price

USD $2 - $5 / Piece

300 Pieces(Min.Order)

Supply Ability 1500 Piece / Pieces per Month
Port Yantian Shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Size	Customized Sizes
Material	Acrylic		Shape	Round

Product Description

Specifications
It is made by vacuum forming which need vacuum forming,cutting,CNC,scraping and packing with excellent quality with best price

About us:
We are one of the most professional manufacturer of vacuum forming products as customer's design for over 10 years in Shenzhen.(We move to new address since Oct15,2014) We have our own experienced mould technicians and CNC mould machines. We have adopted vacuum thermoforming in order to minimize the product development cost for customers. We provide one stop service including mould design and manufacturing, production and processing. In order to reduce development and production lead time, We can meet customers different requirements of thick vacuum forming products.

Vacuum forming plastic product productive process.
1.Extruding plastic sheet:ABS, HIPS, PP, PE, PC, PETG, PMMA resin granules are extruded or co-extruded into thermoplastic sheet--textured, smooth, gloss or matt, fire-retarded or UV resisted

2.Vacuum forming to shape:  After being heated, the plastic sheet is stretched onto or into a mould, and held against the mold by applying vacuum between the mould surface and the sheet to form desired shapes.

3.Cooling to maintain shape: Once formed the plastic need to cool before being released from the mould. To speed up the cooling cycle, fans are fitted and activated once the plastic part is formed.

4.Making large product:Our machine could be restructured to make larger plastic ABS thick vacuum forming plastic shell, with maximun dimensions of 3000*1800*1000* (L*W*H*T)

5.Trimming edges:  Extra material is firstly trimmed before more accurate processing. Sawing is often used in this stages. Polishing is made additioanlly to smoothen the edges.

6.Drilling holes:   Drilling oftens follow the trimming. Other post forming processes include decoration, printing, strengthening, reinforcing and assembly.

7.CNC Processing:  For more accurate and faster speed post thick ABS vacuum forming plastic shell processing, CNC is often used. The machine is computer programmed to select the correct cutting tools and angle to suit each cutting area.

8.Examination and checking:  Before packaging, all our thick vacuum forming samples and products will be carefully checked in terms of dimensions, surface finish, stenghth, colour requirements and so on.

9.Cleansing and Packaging  All ABS thick vacuum forming plastic shells are cleaned before packaging. Products are wrapped with plastic film to prevent scratches and cartoon boxs are used or other methods are applied as required.

Advantages:

1 Reliable and more professional.

2 Our professional engineer can make products and mould design by software CAD. UG. PROE. Solid work and Catia according your request.

3 Made-to-order, completely customized, available for OEM/ODM service.

4 standard mould base, lower mold cost, we have own experienced mold technicians.

5 Send sample with test results to customers for checking.

6 ISO 2008 certified manufacturer.

7 the max size can reach 3000*2000*800mm, the thickness is 1-10mm, the precision can be reached 0.3MM.

8 Fabrication: Vacuum forming, CNC trimming and treatment, engraving or silkscreen printing logos, polishing and scraping process etc.

9 Our plastic vacuum forming products are widely applied in toy, catering auto, mechanism, household appliance, tourism, printing, medical equipment, architecture, touring, advertising, furniture etc.

Buying Guides
1)Customers provide 3D design drawing or sufficient info ( leng x widht x highx thickness, material, colors etc)
2)We offer quotation in time
3)Once confirmed price,we arrange to build mold according to customer's design drawing
4)Make samples for customer approved
5)Arrange mass production after sample approved by customers
6)Timely complete production for on-time delivery.

Welcome to inquiry!
