Help CenterThread or Tapered Cross Bits
Related Products
-
Tapered Rock Drill Bits Button Rock Drill Bits Chisel Bits Cross BitsUS$ 3.6 - 30.68MOQ: 1000 Pieces -
JYG Cold Pressing Tungsten Carbide Button BitsNegotiableMOQ: 500 Pieces
-
High Quanlity Tapered 7 Tips Button BitsUS$ 10 - 15MOQ: 500 Pieces
-
Tungsten Carbide 8 Tips Button BitsNegotiableMOQ: 500 Pieces
-
Tapered 8 Tips Button BitsNegotiableMOQ: 500 Pieces
Specifications
1.Cross tools Manufacturer2.Diameter: 20mm to 70mm
3.Taper degree:6 7 11 12
4.Thread: R22 R25 R28 R32 R38 and etc
Shandong Yanggu Rock Drilling Tools Factory is manufacturer and exporter of Rock Tools such as Cross Drill Bits , Chisel Drill Bits, Taper Drill Rods, Thread Drill Bits and other Rock Tools.
1. Bit Type: Cross bit
2. Diameter : 28mm - 70mm
3. Taper: 6°, 7 °, 11°, 12°
4. Bottom Hole: 22mm, 25mm
5. Bit Body: Short skirt and Long skirt
6. Water Hole: 3
The taper cross bits can be used under any rock drilling condition because of it's comprehensive adaptability.
Taper chisel bit is mainly used for hard rock, tapered cross bits and tapered button bit are mainly used for fissural rock.
The tapered cross bit is mainly used for diging into mine laneway and blasting holes in all drilling works matched with the taper drill rod. For different rock, we choose the different alloy to extend the working life of the taper cross bits.
All the taper cross bits have to be reground at regular intervals to crush rock efficiently.
We choose different material and size for the taper cross bits in order to adapt the different rock formations and working conditions.
