56W LED Street Light Meanwell Driver & Bridgelux Chips,CE & RoHS

Model:QF-SLLD-001-56W

56W LED Street Light

Meanwell HLG-60H & Bridgelux 45mil LED

Specification:

Input voltage:AC85-277v
Power supply:Meanwell HLG driver
Power:56W
Color temperature:2700-7000K
Protection level:IP65
LED quantity:Bridgelux 45mil,1W*56PCS
Carton Size:530*330*180mm
Weight:6.4kg/pcs

Product Feature:

1,Adopt unique modular cooling structure to solve the problems of the traditional integration type heat dissipation

structure.This unique structure also Ensure the reliability of the leds.

2,Practice"ultrashort heat conduction path"concept,by reducing unnecessary intermediate medium,with high quality and low

thermal resistance materials,to simplify heat conduction path from the LED chip to the heat dissipation shell greatly to make

the thermal resistance of the whole lamp reduced greatly,to conduct the thermal more smoothly.

3,The unique light distribution design.Adopt free surface lens to realize accurate light distribution.The light distribution curve

was designed targeted optimization according to the practical road conditions.

4,The unique secondary light distribution and direct reflect mixture design,no light pollution,no Lens Flare,No RF interference,

Light transmittance as high as 98%.

5,Use High quality Ming weft power supply,with input Voltage 100-277V.Power supply efficiency is more than 90%,The power

factor is greater than 0.92,with compulsory UL certification.

6,Use imported original Bridgelux chip,3W LED Lamp beads with high light,high reliability,life span more than 50,000 hours.

7,No pollution to grid.Power factor can be 0.90 or higher,harmonic distortion can be 10%or less,EMI conforms to the global

index,so as to Reduce the electric energy loss of the power supply circuit and avoid the high frequency interference pollution to

power grid.

8,With light and thin appearance.LED street lamps with high-power can reduce wind drag and weight effectively,lighten the load

to the lamp pole,enhance the safety factor.

9.The luminous efficiency of the whole lamp is more than 90LM/W,can replace 150W high voltage sodium lamp

Distribution of Iluminumce:

The Reliablity of Product:

Image of 56W LED Street Light:

1. Topten Industrial (HK) Limited is a professional led lights manufacturer based in Shenzhen China.The company established in 2000,till now we have more than 10 years experience in this field.
2. The company management in accrodance with ISO9001:2008 standard.
3. Products with CE,EMC & LVD,PSE and SAA certification.

• Free shipping for change and return services if there is any problem comes with the quality of our products.
• Absolutely provide 3 years long warranty period for quality.
• Customized & OEM services are available.
